Eyemax DT 624V STORM Vandal Dome Camera: 650 TVL, 3D DNR, 2.8~12mm, Double-Scan WDR, ICR, DUAL power
Images are for illustration purpose and may not show the actual product.
Model:
DT 624FV
Item #: 77
Manufacturer: Eyemax
MSRP:
$350.00
Our Price:
$145.00
(You save: $205.00)
- STORM® series camera : IP-68 Water & Vandal-proof
- Easy Twist and Lock Installation : No drilling thru camera required (Drill hole guide included)
- 3-Axis Construction : By adjusting '3-Axis' control, you get a straight view regardless whether camera is installed on a wall or ceiling
- TRUE Day & Night : ICR (IR-Cut Filter Removal)
> Daytime Advantage : 'IR-Cut Filter' blocks infrared light causing color distortion.
> Night-time Advantage : By removing the 'IR-Cut Filter' at night, camera can take advantage of infrared light to enhance image brightness.
- 1/3" Sony Double Scan color CCD sensor with HERO Chipset
- High Resolution - 650 (H) TV Line in Color, upgraded from 600 TVL
- Minimum Illumination - 0.3Lux (Color) / 0.0001 Lux (Sens-up ×256)
- Double Scan Wide Dynamic Range (DS-WDR) : shows more detail level in dark area at full realtime (30fps) speed
- 2.8~12mm Auto-Iris Zoom Lens Installed
- SENS-UP : intensified low light
> Instead of changing camera mode to B&W for enhancing image brightness, it stays in color mode and increases its shutter speed to gather more light to bright up the image.
- HLM - High Light Mask Function
- DIS - Digital Image Stabilizer
- LSC - Lens Shading Compensation
- OSD (On Screen Display) - Easy camera setup
- 3DDNR (3D Digital Noise Reduction) - Clear motion noise
- DC 12V or AC 24V Dual Power : Automatically detects by power input
AUTO IR CUT FILTER REMOVAL : ICR
At daytime, IR light is filtered away in the camera by the IR-cut filter in order to render color images that humans are used to. When light conditions are too dark to render color images, the IR-cut filter is automatically removed to enable the camera to make use of the IR light to produce a high quality black & white video.
OSD CAMERA SETUP
It has a small program built-in to the camera to help users to setup the camera function without difficulties. No more reading a manual and tipping dip-switches to configure the camera.
VANDAL-RESISTANT CASE
The poly-carbonated impact resistant dome can sithstand repeated blows from a 10-pound hammer and not break. They are perfect for prisons, banks, military installations and other high risk areas.
3-AXIS DOME CONSTRUCTION
Accompanying with 3-Axis construction, the Dome camera can be rotated, shifted horizontally or vertically so you can position the camera to get the pictures you need
| 650 TV Lines |
| 1/3 inch SONY Double Scan CCD |
| 811(H) × 508(V) 410K pixels |
| 768(H) × 494(V) 380K pixels |
| 2:1 Interlace |
| Internal |
| Horizontal : 15.734KHz / Vertical : 59.94Hz |
| More than 52dB (AGC off) |
| CVBS : 1.0Vp-p / 75ohm |
| 0.3 Lux at F1.2 (Color) / 0.0001 Lux(Sens-up x256) |
| ATW / AWC / PUSH / Manual |
| Auto / Manual (1/60 sec ~ 1/100,000 sec) |
| Auto / Off |
| Built-in |
| Low / Middle / High / HLM / Off Selectable |
| Low / Middle / High / Off Selectable |
| Low / Middle / High / Off Selectable |
| Auto / Color / BW / CDS |
| ON / OFF (6 Zone) |
| ON / OFF (240 Zone) |
| FREEZE / V-FLIP / H-FLIP / ROTATE / NEGA : All ON / OFF Adjustable |
| ON / OFF |
| ON / OFF |
| ON (×1~10) / Off |
| Adjustable |
| -10°C~+40°C(14°F ~ 104°F) / 30~80% RH |
| -20°C~+60°C(-4°F ~ 140°F) / 20~90% RH |
| DC 12V/AC 24V |
