It has a small program built-in to the camera to help users to setup the camera function without difficulties. No more reading a manual and tipping dip-switches to configure the camera.
The poly-carbonated impact resistant dome can sithstand repeated blows from a 10-pound hammer and not break. They are perfect for prisons, banks, military installations and other high risk areas.
Accompanying with 3-Axis construction, the Dome camera can be rotated, shifted horizontally or vertically so you can position the camera to get the pictures you need
| Resolution | 650 TV Lines |
| Sensor | 1/3 inch SONY Super HAD II CCD |
| Total Pixels | 811(H) × 508(V) 410K pixels |
| Effective Pixels | 768(H) × 494(V) 380K pixels |
| Scanning System | 2:1 Interlace |
| Frequency | Horizontal : 15.734KHz / Vertical : 59.94Hz |
| S/N (Y signal) | More than 50dB (AGC off) |
| Video Output | CVBS : 1.0Vp-p / 75ohm |
| Min. Illumination | 0.3 Lux at F1.2 (Color) / 0.002 Lux(B/W Sens-up x256) |
| White Balance | ATW / AWC / PUSH / Manual |
| Electronic Shutter Speed | Auto / Manual (1/60 sec ~ 1/100,000 sec) |
| WDR (Wide Dynamic Range) | Auto / Off |
| OSD | Built-in |
| Backlight Compensation | Low / Middle / High / HLM / Off Selectable |
| AGC (Auto Gain Control) | Low / Middle / High / Off Selectable |
| 3D DNR | Low / Middle / High / Off Selectable |
| Day & Night | Auto / Color / BW / CDS |
| Privacy Mask | ON / OFF (6 Zone) |
| Motion Detection | ON / OFF (240 Zone) |
| Image Conversion | FREEZE / V-FLIP / H-FLIP / ROTATE / NEGA : All ON / OFF Adjustable |
| DIS (Digital Image Stabilizer) | ON / OFF |
| LSC (Lens Shading Compensation) | ON / OFF |
| Digital Zoom | ON (×1~10) / Off |
| Sharpness | Adjustable |
| Operating Temperature / Humidity | -10°C~+40°C(14°F ~ 104°F) / 30~80% RH |
| Storage Temperature / Humidity | -20°C~+60°C(-4°F ~ 140°F) / 20~90% RH |
| Power Source | DC 12V / AC 24V Auto Detect |
