Actual Image Recorded

Digital Zoom on above image 1

Digital Zoom on above image 2

| Image Sensor | 2.1 Megapixel, 1/3″ SONY Exmor Color CMOS |
| Video Output Mode (HD-SDI) | 1080p@30 fps, 1080p@25 fps, 720p@60 fps, 720p@50 fps |
| Video Output Mode (TV Out) | NTSC / PAL selectable |
| Effective Pixels (H x V) | 1984 x 1105 |
| Unit Cell Size (H x V) | 2.8 um x 2.8 um |
| Lens | 3.7 mm Lens (3 MP) |
| Lens Type | Fixed Board Lens |
| S/N Ratio | More than 50 dB |
| Min. Illumination | 0.1 Lux |
| Shutter Speed | Auto / Manual |
| Min. Exposure Time | 1/60,000 sec |
| Day & Night | Digital Day & Night |
| IR LED | N/A |
| IP Rating | IP67 (Waterproof) |
| On-Screen Display (OSD) | AD-Key Remote Controller |
| BLC | On / Off |
| DNR | 3D DNR |
| White Balance | Auto / AutoExt / Push / Manual |
| Privacy Masking | 16 Zones |
| WDR | D-WDR |
| Digital Zoom | 1X ~ 8X |
| Digital Slow Shutter | Off, 2x ~ 8x |
| Operating Temperature | -10 °C ~ 50 °C (14 °F ~ 122 °F) |
| Storage Temperature | -20 °C ~ 70 °C (-4 °F ~ 140 °F) |
| Humidity | Operating: Less than 80% RH / Storage: Less than 95% RH |
| Power Consumption | DC 12 V (±10%), Max. 110 mA |
| Dimension | Φ23 x 77.5 mm (Φ0.9 x 3.1 inch) |
| Weight | 90 g (0.2 lb.) |
