| Image | |
| Image Sensor | 1/3" CMOS |
| Horizontal Resolution | 1920x1080P |
| Frame speed | 30fps(NTSC)/25fps(PAL) |
| Lens | |
| Focal Length | 3.3-12mm varifocal lens |
| Focus | Manual |
| Zoom | Manual |
| ICR | Yes |
| Electrical | |
| Video System | NTSC / PAL |
| Video Scanning Type | 2:1 Interlace |
| Sync. System | Internal |
| S/N Ratio | ≥54dB |
| Min. Illumination | 0.1ux @ F1.2 0Lux（LED ON） |
| Video Output | 1 BNC（PAL/NTSC, 1.0Vp-p，75Ω） |
| Function | |
| Video Compression | H.264 |
| Bit stream Control | CBR, VBR |
| Audio Input/Output | 1 Microphone In, 1 Microphone Out |
| Audio Compression | G711 |
| Audio Bit Stream | 6.3Kbps |
| Stream | 256kbps～12288 kbps 256kbps～6144 kbps 128kbps～2560 kbps 64kbps～1024kbps |
| Remote user | six users online simultaneous |
| RS485 | RS485 x1 |
| Audio | Audio in x 1; Audio out x 1 |
| Alarm | Alarm in; Alarm out |
| Ethernet | 1 Ethernet (10/100 Base-T) RJ-45 Connector |
| Network Protocols: |
TCP/IP, DHCP, PPPoE, DDNS, SMTP, UPnP，RTSP,NTP |
| Compliance | Onvif v1.01 or v1.02 (v2.1 READY) |
| SD Card | Support Micro SD/HC, Mini SD/HC with converter |
| Infrared LED | |
| Infrared Red Lamps | 36pcs IR LED |
| IR Distance | 30m |
| Power | |
| Supplied Voltage | DV12V/1.5A |
| POE | 802.3af POE(Power over Ethernet) |
| Environment | |
| Wealther-protection | IP66 |
| Operating Temperature | 14°F ~ 131 °F (-10℃ ~ 50 ℃) |
| Storage Temperature | -4°F~ 140 °F (-20℃ ~ 60 ℃) |
| Humidity | 10%-85%RH |
| Mechanical | |
| Chasis Material & Color | Metal & White |
| Product Dimension | 330mm(L) x 80mm(W) x 82mm(H) |
| Product Net Weight | 1..87lb(0.85kg) |
| Packing | |
| Qty | 20pcs |
| Carton Dimension | 710mm(L)*32.2mm(W)*60mm(H) |
| Carton Gross Weight | 25.1Kg |
| Accessories | |
| Bracket | - |
| Screw | 3 |
| Expansion Tube | 3 |
| Screwdriver | 1 |
| Manual | 1 |
| CD | 1 |
