| PENTAPLEX |
| Real-Time |
| 30 fps (1080p) / 60 fps (720p) |
| 4Ch (BNC) |
| HD – SDI (SMPTE 292M) |
| HDMI |
| 1920x1080 (P), 1920x1080 (I) , 1280x720 (P), 1440x900 |
| VGA |
| HDMI (Multi Channel Display), HD-SDI ( SMPTE 292M ) |
| 4/1 |
| 4/1 |
| 1/4 |
| Graphic User Interface |
| Auto Detection / H.264 Advanced |
| Highest / High / Normal / Low |
| Schedule / Continuous / Event (Motion, Alarm) |
| SATA up to 2 HDD |
| 2 × USB (Front) |
| On / Off |
| Selectable / Up to 4× |
| Camera adjustment & position change / Freeze / Audio on |
| Adjustable GRID (22 × 15) |
| 5 Level motion detection |
| Video is hidden in Live view but it is recorded |
| Supported recent PTZ camera protocol / Preset up to 255 / RS 485 / RS 232 |
| Block the private zone in live camera view |
| By NTP(Network Time Protocol) |
| Via USB & Auto firmware upgrade via Network |
| Auto Detect & Monitoring HDD’s problem |
| Motion / Alarm In / Video loss |
| Recording, e-Mail notification, Log file, Send message to Remote, Buzzer, Pop Up Window, Alarm, PTZ preset |
| Yes (Up to 60 sec / Up to 100 sec) |
| SMPTE 292M (1080p or 720p) |
| 4 Levels ( Low / Normal / High / Highest ) |
| ×1, ×2, ×4, ×8, ×16 |
| Search by time with calendar / Search by event |
| Select specific time period and playback repeatedly |
| Frame by frame |
| Search only event and playback without interval |
| Live monitoring during playback, Playback camera change, Freeze and Digital zoom |
| DVR format |
| DVD / USB device |
| Static IP, DHCP, DDNS |
| RJ45 (10/100/1000 Mbps), Ethernet |
| SMS, Web Viewer, Smart Phone Viewer (Android, I-phone) |
| 350(W) × 258(D) × 70(H) / 3Kg |
| AC 100V ~ 220V (50Hz ~ 60Hz) / 60W |
