| Camera |
| 1/3" progressive scan CMOS |
| 1280 (H) x 1024 (V) |
| 1 Lux (1/60 sec), 0.1 Lux (1/5 sec), (F/1.4, AGC-On, slow shutter-Off) |
| 0.1 Lux (1/60 sec), 0.05 Lux (1/5 sec), (F/1.4, AGC-On, slow shutter-Off) |
| 0 Lux (1/60 sec), (F/1.4, AGC-On, slow shutter-Off) |
| Automatic (Balanced, Speed Priority, Quality Priority), Manual (1/5 ~ 1/4000 sec) |
| Automatic, Manual (2800K ~ 8500K) |
| Lens |
| Yes |
| Yes (with removable IR-cut filter) |
| 4.0 mm |
| F / 1.5 |
| CS Mount |
| 1/3" |
| 80.4° |
| 65.4° |
| 49.9° |
| Yes |
| No |
| Fixed |
| Operation |
| H.264, MPEG4 and MJPEG |
| Dual Streams from H.264, MPEG4 and MJPEG |
| 15 fps at 1280 x 1024, 30 fps at 640 x 512
* The frame rate and performance may vary depending on the number of connections and data bitrates (different scenes). |
| Brightness, Contrast, Saturation, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation, Shutter Speed |
| G.711 |
| 1 input (Wet Contact , 7V ~ 30V) |
| 1 digital output (10A 250V AC; 10A 125V AC; 5A 100V DC ) |
| Video Resolution |
| 1280 x 960, 640 x 480, 320 x 240 |
| 1280 x 1024, 640 x 512, 320 x 256 |
| 640 x 480, 320 x 240 |
| 640 x 512, 320 x 256 |
| Network |
| 10/100 Ethernet |
| HTTP, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA |
| Mechanical |
| C / CS-Mount |
| DC Jack, PoE |
| RJ-45 |
| 1 In (Using the built-in microphone or externally connecting a microphone)
1 Out (Stereo phone jack, 3.5 mm / 0.14 in) |
| 5-pin terminal block, pitch 3.5 mm / 0.14 in |
| Not functional |
| Micro SD/SDHC memory card slot (for Class 6 card or above) |
| BNC connector (640 x 480 resolution) |
| 1 LED with two colors |
| General |
| 0 °C ~ 50 °C / 32 °F ~ 122 °F |
| 10% to 90% (no condensation) |
| 12V DC / PoE |
| 9.2 W |
| 115 x 65 x 60 mm / 4.52 x 2.55 x 2.36 in |
| 450 g / 0.99 lb |
| CE, FCC, C-Tick, RoHS compliant |
| Power over Ethernet |
| IEEE 802.3af Power over Ethernet / PSE |
| End-Span |
| Per Port 48V DC, 350mA. Max. 15.4 watts |
| Web Interface |
| Web-based configuration |
| Firmware upgrade through Web Browser or Utility |
| Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O control, audio, Wide Angle Lens Dewarping, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Text Overlay |
| Czech / Danish / English / French / German / Hebrew / Hungarian / Italian / Japanese / Polish / Portuguese / Russian / Serbian / Simplified Chinese / Spanish / Traditional Chinese
* Bulgarian, Dutch, Greek,Indonesian, Lithuanian, Norwegian, Persian, Romanian, Slovakian, Slovenian, Thai and Turkish are only supported in V1.08 or later. |
| Applications |
| GV-NVR, GV-System, GV-Backup Center, GV-Recording Server
* GV-Backup Center and GV-Recording Server are supported in V1.08 or later |
| GV-AView for Android Smartphone, GV-Eye HD for iPad, GV-Eye for iPhone and iPod Touch, GV-GView for Windows PDA, GV-MSView for Windows Smartphone, GV-SSView for Symbian Smartphone, 3G-enabled phone |
| IE , GV-MultiView |
| GV-Control Center, GV-Center V2, GV-VSM |
