> Item #504

GEOVISION 2 Mega-Pixel IP Camera, H.264 Cube, Built-in Microphone and Speaker, Active Tampering Alarm

Images are for illustration purpose and may not show the actual product.

Click to Enlarge

Additional Images:

Additional Image for GEOVISION 2 Mega-Pixel IP Camera, H.264 Cube, Built-in Microphone and Speaker, Active Tampering Alarm: GV-CB220

Additional Image for GEOVISION 2 Mega-Pixel IP Camera, H.264 Cube, Built-in Microphone and Speaker, Active Tampering Alarm: Ceiling Mount

Additional Image for GEOVISION 2 Mega-Pixel IP Camera, H.264 Cube, Built-in Microphone and Speaker, Active Tampering Alarm: Wall Mount

Additional Image for GEOVISION 2 Mega-Pixel IP Camera, H.264 Cube, Built-in Microphone and Speaker, Active Tampering Alarm: Desk Mount

Additional Image for GEOVISION 2 Mega-Pixel IP Camera, H.264 Cube, Built-in Microphone and Speaker, Active Tampering Alarm: Dimension 1

Additional Image for GEOVISION 2 Mega-Pixel IP Camera, H.264 Cube, Built-in Microphone and Speaker, Active Tampering Alarm: Dimension 2

Model: GV-CB220
Item #: 504
Manufacturer: GeoVision

MSRP: ~~$455.00~~
Our Price:

$325.00

(You save: $130.00)

This Model has been discontinued and available only by special order.
Please follow the link for replacing wireless model: GV-CBW220

If you specifically need this model, please contact us for availability

1/2.5’’ Progressive Scan CMOS

Stream 1 from H.264 and MJPEG;
Stream 2 from H.264, MPEG4 and MJPEG

Indoor 2 Mega-Pixel Camera: Up to 30 fps at 1920 x 1080

Built-in speaker and microphone

Micro SD/SDHC Card Slot

G.711 and AAC audio codec

Motion detection

Tampering alarm

Privacy mask

IP address filtering

3GPP / ISMA

Megapixel lens

16 languages on Web interface

* No SD/SDHC card slot & local storage function for Argentina

Active Tampering Alarm

Tampered	Focus Change	Camera Shift

Camera
Image Sensor		1/2.5" progressive scan CMOS
Picture Elements		1920 (H) x 1080 (V)
Minimum Illumination	Color	1 Lux (1/30 sec), 0.5 Lux (1/5 sec)
Shutter Speed		Automatic, Manual (1/5 ~ 1/8000 sec)
White Balance		Automatic, Manual (2800K ~ 8500K)
Lens
Megapixel		Yes
Day/Night		Yes (electronic)
Lens Type		Fixed
Focal Length		3.35 mm
Max Aperture		F/2.4
Image Format		1/3"
Angle of view	Diagonal	142°
	Horizontal	131°
	Vertical	112°
Operation	Focus	No
	Zoom	No
	Iris	Fixed
Operation
Video Compression		H.264, MPEG4, MJPEG
Video Stream		Stream 1 from H.264 and MJPEG Stream 2 from H.264, MPEG4 and MJPEG
Frame Rate		30 fps at 1920 x 1080 * The frame rate and the performance may vary depending on the number of connections and data bitrates (different scenes).
Image Setting		Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker-less, Image Orientation, Shutter Speed, Backlight Compensation
Audio Compression		G.711, AAC (16 kHz / 16 bit) * AAC is only supported by GV-System V8.5 or later
Video Resolution
Main Stream	4:3	1600 x 1200, 1280 x 960, 640 x 480, 320 x 240
	16:9	1920 x 1080, 1280 x 720, 640 x 360, 448 x 252
	5:4	1280 x 1024, 640 x 512, 320 x 256
Sub Stream	4:3	640 x 480, 320 x 240
	16:9	640 x 360, 448 x 252
	5:4	640 x 512, 320 x 256
Network
Interface		10/100 Ethernet
Ethernet Protocol		HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, 3GPP/ISMA, RTSP, PSIA, SNMP, QoS (DSCP)
Mechanical
Lens Mounting		M12 mm
Temperature Detector		Yes
Connectors	Power	DC Jack
	Ethernet	Ethernet (10/100 Base-T), RJ-45
	Audio	Built-in speaker & microphone
	Local Storage	Micro SD/SDHC memory card slot (for Class 6 card or above)
LED Indicator		2 LEDs: Status, LAN
General
Environment Temperature		0 °C ~ 50 °C / 32 °F ~ 122 °F
Humidity		10% to 90% (no condensation)
Power Source		12V DC
Power Consumption		4 W (max. 0.35A at 12V DC)
Regulatory		CE, FCC, C-Tick, RoHS compliant
Dimensions		60 x 84.8 x 39 mm / 2.36 x 3.34 x 1.54 in
Weight		80 g / 0.18 lb
Web Interface
Installation Management		Web-based configuration
Maintenance		Firmware upgrade through Web Browser or Utility
Access from Web Browser		Camera live view, video recording, change video quality, bandwidth control, image snapshot, audio, Wide Angle Lens Dewarping, Picture in Picture, Picture and Picture, Privacy Mask, Tampering Alarm, Text Overlay
Language		Czech / Danish / English / French / German / Hebrew / Hungarian / Italian / Japanese / Polish / Portuguese / Russian / Serbian / Simplified Chinese / Spanish / Traditional Chinese
Applications
Network Storage		GV-NVR, GV-System, GV-Backup Center, GV-Recording Server
3G Mobile Phone		Built-in player for 3GPP / ISMA
Live Viewing		IE , GV-MultiView
CMS Server support		GV-Control Center, GV-Center V2, GV-VSM
