FUJINON Megapixel Lens - YV4.3x2.8SA-SA2: 2.8~12mm WIDE, 3 MP support, Auto-Iris, Built-In ND Filter
Images are for illustration purpose and may not show the actual product.
Additional Images:
Model:
LA MPFU2812AS
Item #: 384
Manufacturer: Fujinon
MSRP:
$186.00
Our Price:
$104.00
(You save: $82.00)
- Manufacturer Part Number: YV4.3x2.8SA-SA2
- 2.8~12mm Vari-Focal Adjustable Lens
- Wide Angle to Telelphoto Long Focal
- Megapixel Lens supporting 3 MP
- CS mount
- Built-in ND filter
- DC Auto Iris
- Metal Mount
- Aspherical Lens
- F1.4 Wide Aperture Rate
High image-quality monitoring with optical performance supporting 3 megapixels. Wide f2.8-12mm range accommodates various applications. Designed to maximize optical performance with high-accuracy aspheric lens, low-dispersion glass, and high refractive-index glass. Built-in ND filter of T360, supporting high sensitivity cameras.
ND Filter
ND filter allows greater flexibility to change the aperture, exposure time and/or motion blur of subject in different situations and atmospheric conditions.
| CS |
| 2.8 mm - 12 mm (4.3x) |
| Manual |
| F1.4 - T360 (Equivalent to F360) |
| Auto (DC Type) (*1) |
| Manual |
| 7.83 mm |
| 455 mm |
| 753 mm × 476 mm |
| 131 mm × 98 mm |
| 476 mm × 329 mm |
| 98 mm × 73 mm |
| 895 mm × 365 mm |
| 143 mm × 80 mm |
| 538 mm × 260 mm |
| 106 mm × 60 mm |
| 100°02′ × 74°03′ |
| 23°26′ × 17°36′ |
| 74°03′ × 55°06′ |
| 17°36′ × 13°13′ |
| 109°33′ × 60°80′ |
| 25°31′ × 14°23′ |
| 80°56′ × 44°51′ |
| 19°10′ × 10°48′ |
| ∞ - 0.3 m |
| - |
| 80 g |
| 190 Ω |
| 500 Ω |
| 23 mA (Max.) at DC 4V |
|
