Actual Image Recorded

Digital Zoom on above image 1

Digital Zoom on above image 2

| Image Device | 2.1 Mega Pixel, 1/3” Exmor SONY CMOS |
| Video Output Mode |
HD-SDI : 1080p@30fps, 1080p@25fps, 720p@60fps, 720p@50fps TV Out : NTSC / PAL Selectable |
| Effective Pixels | 1984(H) x 1105(V) |
| Unit cell size (um) | 2.8(H) x 2.8(V) |
| S/N Ratio | More than 50 dB |
| Min. Illumination | 0 Lux |
| Video Output | HD-SDI / 1.0 Vp-p Composite (75Ω) |
| Lens | f=3.6mm Board Lens |
| Manual Shutter Speed |
1/30(25), 1/60(50), 1/120(100), 1/240, 1/500, Manual Shutter Speed 1/1K, 1/2K, 1/4K, 1/8K, 1/16K, 1/30K, 1/60K |
| Shutter speed | Auto / Manual Selectable |
| D-WDR / BLC | OFF / BLC / D-WDR |
| AGC | Max. 29 dB |
| 3DNR | OFF / LOW / MIDDLW / HIGH |
| White Balance | AUTO / AUTOext / PUSH / MANUAL |
| Digital Zoom Ratio | 1x ~ 20x |
| Digital Slow Shutter | Off, x2 ~ x8 |
| Privacy Masking | Zone 24 ea, On / Off |
| Day & Night | True Day & Night with ICR Mechanism |
| IR LED | 850nm, 20ea, up to 10m (32 feet) |
| OSD | Built-in |
| IP Rating | IP66 (Weather Proof) |
| Operating Temperature | 14˚F~122˚F (-10˚C~+50˚C) |
| Storage Temperature | -4˚F~140˚F (-20˚C~+60˚C) |
| Humidity | Operating : Less than 80% / Storage : Less than 95% |
| Power Consumption | DC12V (±10%) Max. 390 mA |
| Dimensions (mm) | Ø93 x 63 |
| Weight | Approx. 330 g |
| Optional Colors | Black / White |
