| System Requirements | ||
| OS | 32 bit: Windows XP / Vista / 7 / Server 2008 64 bit: Windows 7 / Server 2008 * 32‐bit operation system is only supported OS in GV‐System V8.5.0.0 or later |
|
| GV-System Version | GV-System v8.4.0.0 with patch files or later | |
| Browser | Internet Explorer 7.x or later | |
| Camera | ||
| Image Sensor | 1/2.5" progressive scan CMOS | |
| Picture Elements | 2048 (H) x 1944 (V) | |
| Minimum Illumination | 4 Lux (1/30 sec), 2 Lux (1/5 sec) | |
| Shutter Speed | Automatic , Manual (1/5 ‐ 1/8000 sec) | |
| White Balance | Automatic, Manual (2800K~8500K) | |
| Gain Control | Automatic | |
| S/N Ratio | 45 dB | |
| Lens | ||
| Megapixel | Yes | |
| Day/Night | Yes (electronic) | |
| Iris | Fixed Iris | |
| Focal Length | 1.05mm | |
| Maximum Aperture | F/2.8 | |
| Mount | M12, Pitch 0.5mm | |
| Image Format | 1/2" | |
| Operation | Focus: none, Zoom: none, Iris: Fixed | |
| Operation | ||
| Video Compression | H.264, MJPEG | |
| Video Streaming | Single stream from H.264 or MJPEG | |
| Frame Rate | 15 fps | |
| Image Setting | Brightness, Contrast, Sharpness, Gamma, White Balance, Flicker‐less, Backlight Compensation, Image Orientation, Shutter Speed, Day / Night, WDR, Defog |
|
| Audio Compression | G.711, AAC (16 kHz / 16 bit) * AAC is only supported by GV‐System V8.5 or later |
|
| 2-way Audio | Yes | |
| Sensor Input | 1 Input (Dry Contact) | |
| Alarm Output | 1 Output | |
| Network | ||
| Interface | 10/100 Ethernet | |
| Protocol | HTTP, HTTPS, TCP, UDP, SMTP, FTP, DHCP, NTP, UPnP, DynDNS, RTSP, PSIA, SNMP, QoS (DSCP), ONVIF | |
| Mechanical | ||
| Lens Mounting | M12, Pitch 0.5mm / 0.02 in | |
| Temperature Detector | Yes | |
| Connectors | Power | Terminal block (3 pin ), PoE |
| Ethernet | Ethernet (10/100 Base‐T), RJ‐45 Connector | |
| Audio | Built‐in microphone and speaker | |
| Digital I/O | I/O wire | |
| Auto Iris | none | |
| Local Storage | Micro SD/SDHC/SDXC memory card slot (for Class 6 card or above) | |
| TV-Out | none | |
| Power | Terminal block (3 pin), PoE | |
| General | ||
| Operating Temperature | 0 °C ~ 50 °C / 32 °F ~ 122 °F | |
| Humidity | 10% to 90% (no condensation) | |
| Power Source | 12V DC / 24V AC / PoE (IEEE802.3af) | |
| Max. Power Consumption | 5 W | |
| Dimensions | Camera Body: 6.30 diameter x 1.88 in Cable Length: 1m / 3.28 ft Cable Diameter: 8mm / 0.31 in Maximum Connector Diameter: 28.5mm / 1.12 in |
|
| Weight | 650g / 1.43 lb | |
| Regulatory | CE, FCC, C‐Tick, RoHS compliant | |
| Power over Ethernet | ||
| PoE Standard | IEEE 802.3af Power over Ethernet / PSE | |
| PoE Power Supply Type | End-Span | |
| PoE Power Output | Per Port 48V DC, 350mA. Max. 15.4 watts | |
| Web Interface | ||
| Installation Management | Web-based configuration | |
| Maintenance | Firmware upgrade through Web Browser or Utility | |
| Access from Web Browser | Camera live view, video recording, change video quality, bandwidth control, image snapshot, digital I/O control, audio, Picture in Picture, Picture and Picture, Privacy Mask, Visual Automation, Tampering Alarm, Auto Pan function, virtual PTZ, motion detection, wide angle lens dewarping, text overlay |
|
| Language | Arabic / Bulgarian / Czech / Danish / Dutch / English / Finnish / French / German / Greek / Hebrew / Hungarian / Indonesian / Italian /Japanese / Lithuanian / Norwegian / Persian / Polish / Portuguese / Romanian / Russian / Serbian / Simplified Chinese / Slovakian / Slovenian / Spanish / Swedish / Thai / Traditional Chinese / Turkish |
|
| Applications | ||
| Network Storage | GV‐NVR, GV‐System, GV‐Backup Center, GV‐Recording Server | |
| Live Viewing | IE, GV-Multi View | |
| CMS Server support | GV‐Control Center, GV‐Center V2, GV‐VSM | |
