Type |
Board Lens |
|||
|
Focal Length |
3.6 |
6 |
8 |
12 |
|
Aperture |
F2.0 |
F2.0 |
F2.0 |
F2.2 |
|
Angle of View |
92Ëš |
53Ëš |
40Ëš |
28Ëš |
| Signal System | NTSC |
| Image Sensor | 1/3” 960H SONY EXview HAD CCD II |
| Scanning System | 2:1 Interlace |
| Horizontal Resolution | 750TV Lines |
| Scanning Frequency (H) | 15.734 KHz |
| Scanning Frequency (V) | 59.94 Hz |
| Total Pixels (H x V) | 1020 x 508 |
| Effective Pixels (H x V) | 976 x 494 |
| Synchronization | Internal |
| Lens | 2.97, 3.6, 4.3, 6.0, 8.0, 12.0 mm |
| Lens Type | Fixed Board Lens |
| S/N | More than 50dB (AGC: Off) |
| Gamma | r = 0.45 |
| Min. Illumination | 0.1 Lux |
| Shutter Speed | 1/60 ~ 1/100,000 sec |
| Day & Night | Digital Day & Night |
| Day & Night Function | Auto, Color, B/W |
| IP Rating | IP67 (Weather Proof) |
| Video Output Level | 1 Vp-p Composite (75 Ω) |
| On-Screen Display (OSD) | Built-in (Joystick) |
| BLC | Off, BLC, HLC |
| DNR | 2D DNR |
| ATR | On / Off (Level Adjustable) |
| White Balance | ATW, Push, User1, User2, Anti CR, Manual, Push-lock |
| Privacy Masking | 4 Zones |
| Mirror | On / Off |
| Motion Detection | 4 Zones |
| Other Function | Brightness, Contrast, Sharpness, HUE, Gain |
| Language Option | English, Japanese, German, French, Russian, Portuguese, Spanish |
| Operating Temperature | 14 °F ~ 122 °F (-10 °C ~ 50 °C) |
| Storage Temperature | -4 °F ~ 140 °F (-20 °C ~ 60 °C) |
| Power Supply | DC 12V (±10%), Max. 83mA |
| Dimension | Φ0.9 x 3 inch (Φ23 x 75.2 mm) |
| Weight | 0.1 lbs (68 g) |
| Certifications | FCC / CE / UL / ROHS |
