EYEMAX XSQ-202P HD-SDI miniature camera: 2 Megapixel HD 1080p image, 4.3mm Pinhole Lens, DNR
Images are for illustration purpose and may not show the actual product.
Model:
XSQ-202P
Item #: 281
Manufacturer: Eyemax
MSRP:
$120.00
Our Price:
$83.00
(You save: $37.00)
- 1/3" SONY CMOS
- HD-SDI: High Definition Serial digital Interface
- HD-SDI (1080P, 720P) / High Resolution (1000 TV Line OVER)
- Day & Night: 1 Lux at F1.2 / 0.1 Lux (B/W)
- DNR (Digital Noise Reduction)
- 4.3 mm Pinhole lens
- HD-SDI cameras are recommended to use only with RG59/RG6 cables with crimp/compressed connectors
What is the benefit of HD-SDI cameras?
HD-SDI stands for High-Definition Serial Digital Interface.
HD camera delivers a megapixel quality video without requiring IT network bandwidth, dropping packets, or reduced resolution from compression. HD camera provides superior surveillance environment compared to conventional VGA camera. HD cameras are easy to work with, and installers can migrate from analog cameras without any additional training.
Actual Image Recorded
Digital Zoom on above image 1
Digital Zoom on above image 2
| Resolution |
HD-SDI(1080p, 720p) |
| Sensor |
1/3" Sony CMOS |
| Total Pixels |
2010(H) × 1108(V) = 2.2M Pixel |
| Effective Pixels |
1944(H) × 1092(V) = 2.1M Pixel |
| Scanning System |
Progressive |
| S/N (Y signal) |
More than 52 dB (AGC Off) |
| Video Output |
SMPTE292M (HD-SDI) |
| Min.Illumination |
1 Lux at F1.2 |
| White Balance |
Auto |
| Electronic Shutter Speed |
Auto (1/30sec ~ 1/60,000sec) |
| Brightness |
Adjustable (0 ~ 20 Step) |
| Sens up |
Off |
| WDR/BLC |
Off |
| HLM |
Off |
| ACE |
Off |
| DNR |
Middle |
| Day & Night |
Auto |
| Privacy |
Off |
| Motion Detection |
Off |
| D.ZOOM |
Off |
| FLIP |
Off |
| Privacy |
Off |
| Motion Detection |
Off |
| D.ZOOM |
Off |
| FLIP |
Off |
| FREEZE |
Off |
| Sharpness |
Off |
| Image Conversion |
Off |
| Language |
English |
| Operating Temperature / Humidity |
14°F~122°F (-10°C~+50°C) / 30%~80% RH |
| Storage Temperature / Humidity |
-4°F~+140°F (-20°C~+60°C) / 20%~90% RH |
| Power |
DC 12V Only |
| Signal Transmission |
The distant difference is occurred according to cable option and other circumstances. (based on RG59: 100M) |
