Actual Image Recorded

Digital Zoom on above image 1

Digital Zoom on above image 2

| Image Device | 2.1 Mega Pixel, 1/2.8” Exmor SONY CMOS |
| Video Output Mode |
HD-SDI : 1080p@30fps, 1080p@25fps, 720p@60fps, 720p@50fps TV Out : NTSC / PAL Selectable |
| Effective Pixels | 1984(H) x 1105(V) |
| Unit cell size (um) | 2.8(H) x 2.8(V) |
| S/N Ratio | More than 50 dB |
| Min. Illumination | 0.1 Lux |
| Video Output | HD-SDI / 1.0 Vp-p Composite (75Ω) |
| Lens | f=3.5 ~ 16mm Mega Pixel Varifocal Lens |
| Lens Control | Manual IRIS, DC IRIS |
| Min. Exposure Time | 1/60,000 sec |
| Shutter speed | Auto / Manual Selectable |
| Flickerless | 60Hz / 50Hz Selectable |
| WDR / BLC | OFF / WDR / BLC Selectable |
| AGC | 0 ~ 38 dB |
| 3DNR | OFF / LOW / MIDDLE / HIGH |
| White Balance | AUTO / AUTOext / PUSH / MANUAL |
| Digital Zoom Ratio | 1x ~ 20x |
| Digital Slow Shutter | Off, x2, x3, x4 |
| Privacy Masking | Zone 24 ea, On / Off |
| Motion Detection | On / Off |
| Day & Night | True Day & Night with ICR Mechanism |
| IR LED | 850nm, Hi-power LED 6ea, up to 40m |
| OSD | Built-in |
| IP Rating | IP66 (Weather Proof) |
| Operating Temperature | 14˚F~122˚F (-10˚C~+50˚C) |
| Storage Temperature | -4˚F~140˚F (-20˚C~+70˚C) |
| Power Consumption | DC12V (±10%), Max. 605 mA / AC24V (±10%), Max. 504 mA |
| Dimensions (mm) | Φ67 x 234 |
| Weight | Approx. 1 kg |
