Actual Image Recorded

Digital Zoom on above image 1

Digital Zoom on above image 2

| Image Device | 2.1 Mega Pixel, 1/3” Exmor SONY CMOS | |
| Video Output Mode |
HD-SDI : 720p@60fps, 720p@50fps, 1080p@30fps, 1080p@25fps TV Out : NTSC / PAL selectable |
|
| Effective Pixels | 1936(H) x 1217(V) | |
| Unit cell size (um) | 2.8(H) x 2.8(V) | |
| S/N Ratio | Max 50dB | |
| Min. Illumination | 1.0 Lux | |
| Video Output | HD-SDI / 1.0 Vp-p Composite (75Ω) | |
| Lens | C/CS Mount | |
| Lens Control | DC IRIS | |
| Manual Shutter Speed |
1/30(25), 1/60(50), 1/120(100), 1/240, 1/500, 1/1K, 1/2K, 1/4K, 1/8K, 1/16K, 1/30K, 1/60K |
|
| Shutter speed | Auto / Manual Selectable | |
| WDR / BLC | OFF / WDR / BLC Selectable | |
| AGC | 0~10 dB | |
| 3DNR | OFF / LOW / MIDDLW / HIGH | |
| White Balance | AUTO / AUTOext / PUSH / MANUAL | |
| Digital Zoom Ratio | 1x ~ 20x | |
| Digital Slow Shutter | Off, x2, x3, x4 | |
| Privacy Masking | Zone 23 ea, On / Off | |
| Motion Detection | On / Off | |
| Day & Night | True Day & Night with ICR Mechanism | |
| OSD | Built-in | |
| Operating Temperature | 14˚F~122˚F (-10˚C~+50˚C) | |
| Storage Temperature | -4˚F~140˚F (-20˚C~+70˚C) | |
| Humidity | Operating: Less than 80% / Storage: Less than 95% | |
| Power Consumption | DC12V | DC12V (±10%), Max. 190 mA |
| Dual | DC12V (±10%) Max. 240 mA / AC 24V (±10%) Max. 3.5 W | |
| Dimensions (mm) | 58(W) x 58(H) x 71(D) | |
| Weight | Approx. 175 g (DC12V) / Approx. 200 g (Dual) | |
| Optional Colors | Black / Metal Silver | |
