Video Signal Format | NTSC / PAL |
Image Sensor | 1/4" Super HAD color CCD |
Total Pixels | NTSC : 811(H) x 508(V) 410KPAL : 795(H) x 596(V) 470K |
Effective Pixels | NTSC : 768(H) x 494(V) 380KPAL : 752(H) x 582(V) 440K |
Horizontal Resolution | 550 TV Lines (Color), 680 TV Lines (B/W) |
Video Signal-to-Noise | 50 dB (AGC Off) |
Zoom | x27 Optical Zoom, x12 Digital Zoom |
Forcal Length | F1.6 ~2.9, f=3.5 ~94.5mm |
Angle of View | H : 55.5°(Wide) ~ 2.24°(Tele) / V : 42.5°(Wide) ~ 1.79°(Tele) |
Zoom Speed | 1.8 sec (Wide to Tele) |
Minimum Illuminance | 0.4 Lux (Color) / 0.02 Lux (B/W), 50 IRE / F1.6 |
Day & Night | Auto / Day / Night (ICR) |
Focus | Auto / Manual / Semi-Auto |
Iris | Auto / Manual |
Shutter Speed | x256 ~ 1/120,000 sec |
AGC | Low / Middle / High / Manual / Off |
White Balance | Auto / Manual (Red, Blue Gain Adjustable. 1800°K ~ 10500°K) |
BLC | BLC / HLC / Off |
Flicerless | Selectable |
SSNR | Low / Middle / High / Off |
Privacy Zone | 8 Masks, Spherical Coordinate |
Stabilization | ON / OFF |
Movement Range | Pan : 360° (Endless)Tilt : 90° |
Speed | Preset : 360° / secJog : 0.05 ~ 360° / sec. (Proportional to Zoom)Swing : 1 ~ 180° / sec |
Preset | 127 Presets (Label, Independent Camera Parameter Setting) |
Pattern | 4 Patterns [1200 Commands (Approx. 5 Minute) / Pattern] |
Swing | 8 Swings |
Group | 8 Groups (MAX. 20 Actions with The Combination of Preset, Pattern and Swing) |
Other Pan/Tilt Function | Auto Flip, Auto Parking, Power Up Action and etc. |
Communication | RS-485 |
Protocol | Pelco-D, Pelco-P Selectable |
OSD | English, Menu / PTZ Information etc. |
Sensor Input | 3 Inputs, Photo-Coupler Type, DC 5V ~ 12V |
Alarm Outputs | 1 Output, Relay Output, MAX. Load DC24V 1A / AC 125V 0.5A |
Fan | Always ON |
Heater | Operation Start from Internal Temperature 10°C |
Operation Temperature | -30°C ~ 50°C / -22°F ~ 122°F |
Power | AC 24V / 1.5A |
