Model

SD40212I-HC

SD42212I-HC

SD42C212I-HC

Camera

Image Sensor

1/2.8″ Exmor   CMOS

Effective Pixels

1944(H) x 1092(V), 2 Megapixels

Horizontal Resolution

≥1000TVL

Scanning System

Progressive

Electronic Shutter Speed

1/1s ~1/30,000s

Min. Illumination

Color: 0.05 Lux/F1.6, B/W: 0.005Lux/F1.6

S/N Ratio

More than 55dB

Resolution

1080P(25/30fps), 720P(25/30/50/60fps)

Video Output

1-channel BNC HDCVI high definition video output/ CVBS standard

definition video output (Can switch)

Camera Features

Day/Night

Auto(ICR) / Color / B/W

Backlight Compensation

BLC / HLC / DWDR (Digital WDR)

White Balance

Auto, ATW, Indoor, Outdoor, Manual

Gain Control

Auto / Manual

Noise Reduction

2D / 3D

Privacy Masking

Up to 24 areas

Digital Zoom

16x

Lens

Focal Length

5.1 mm~61.2mm (12x Optical zoom)

Max Aperture

F1.6~ F3.0

Focus Control

Auto / Manual

Angle of View

H: 51.3° ~ 4.64°

Close Focus Distance

100mm~1000mm

PTZ

Pan/Tilt Range

Pan: 0° ~ 360° endless; Tilt: -2° ~ 90°, auto flip 180°

Manual Control Speed

Pan: 0.1° ~ 300°/s; Tilt: 0.1° ~120°/s

Preset Speed

Pan: 300°/s; Tilt:200°/s

Preset

80(DH-SD) , 255(Pelco-P/D)

PTZ Mode

5 Pattern, 8 Tour, 5 Auto Scan, Auto Pan

Speed Setup

Human-oriented focal length/ speed adaptation

Power up Action

Auto restore to previous PTZ and lens status after power failure

Idle Motion

Activate Preset/ Scan/ Tour/ Pattern if  there is  no command in  the

specified period

Protocol

DH-SD, Pelco-P/D (Auto recognition)

Audio

Interface

1 channel In

Auxiliary Interface

RS485

1

Alarm

2/1 channel In/Out

General

Power Supply

AC24V/1.5A (±10%)

Power Consumption

10W, 19W(Heater on)

10W

Working Environment

-40ºC ~ 60ºC /

Less than 90% RH

-10ºC ~ 60ºC / Less than 90% RH

Ingress Protection

IP66

N/A

Dimensions

Φ186mm×234mm

Φ170mm×155mm

Φ198mm×158mm

Weight

2.3Kg

1.8Kg

2.0Kg
