| Resolution | 1/3" Sensor |
| Signal System | NTSC |
| Sync. System | Internal Sync. |
| Effective Pixels | 768(H) × 494(V) |
| Sensing Area | 4.8mm × 3.6mm |
| Horizontal Resolution | 600 TVL |
| OSD Menu | Support |
| Video Output | 1.0Vp~p75Ω |
| S/N Ratio | More than 50dB (AGC Off) |
| White Balance | Auto Tracking White Balance |
| Shutter Speed | 1 / 50(1 / 60) ~ 1 / 100,000sec |
| ICR | Yes |
| Infrared Lamps | Night / Day On / Off |
| Illumincation for Infrared Switching | 3 Lux |
| Minimum Illumincation | 0 Lux(Infrared Lamps Turn On) |
| Infrared Wavelength | 850nm |
| IR Leds | 24 Pcs |
| IR Radiation Distance | 15~25m |
| Built-in Lens | 3.6mm Mega Pixel Lens |
| Working Temperature | 14°F ~ 122°F |
| Storage Temperature | -4°F ~ 140°F |
| Power Requirement | DC 12V, Max Power Consumption less than 5W (When the infrared lamps turn on) |
