Camera

Image Sensor

1/2.7″ 2Megapixel CMOS

Effective Pixels

1930(H)×1088(V)

Electronic Shutter

1/60s~1/100,000s

Video Frame Rate

30fps@1080P

Synchronization

Internal

Min. Illumination

0.01Lux@F1.2(AGC ON), 0Lux IR on

Video Output

1-channel BNC HDCVI high definition video output

Camera Features

Max. IR LEDs Length

20m, Smart IR

Day/Night

Auto(ICR) / Color / B/W

Noise Reduction

2D

Lens

Focal Length

3.6mm

Angle of View

H: 80.6º(57.55º)

Mount Type

M12

General

Power Supply

DC12V±20%

Power Consumption

Max 2.5W

Working Environment

-30°C~+60°C / Less than 95%RH (no condensation)

Transmission Distance

Over 300m via 75-3 coaxial cable

Ingress Protection

IP66

Dimensions

Φ94.0mm×79.5mm

Weight

0.35kg

Material

Metal
