Model |
HNC5141E |
|
Camera |
||
Image Sensor |
1/3” 4Megapixel progressive scan CMOS |
|
Effective Pixels |
2688(H)x1520(V) |
|
Scanning System |
Progressive |
|
Electronic Shutter Speed |
Auto/Manual, 1/3(4)~1/100000s |
|
Min. Illumination |
0. 01Lux/F1.2 (Color), 0.001Lux/F1.2(B/W) |
|
S/N Ratio |
More than 50dB |
|
Video Output |
1 channel BNC(1.0Vp-p,75Ω) |
|
Camera Features |
||
Max. IR LEDs Length |
N/A |
|
Day/Night |
Auto(ICR)/Color/B/W |
|
Backlight Compensation |
BLC / HLC / WDR(120dB) |
|
White Balance |
Auto/Sunny/Night/Outdoor/Customized |
|
Gain Control |
Auto/Manual |
|
Noise Reduction |
3D |
|
Privacy Masking |
Up to 4 areas |
|
EIS |
Support |
|
Smart focus |
ABF |
|
Lens |
||
Mount Type |
C/CS |
|
Video |
||
Compression |
H.264/H.264B/H.264H/ MJPEG |
|
Resolution |
4M(2688×1520)/4M(2560×1440)/3M(2304×1296)/1080P(1920×10 80)/720P(1280×720)/D1(704×576/704×480)/CIF(352×288/352×24 0) |
|
Frame Rate |
Main Stream |
4M(1~20fps)/3M(1 ~ 25/30fps) |
Sub Stream |
D1/CIF(1 ~ 25/30fps) |
|
Third Stream |
720P(1-20fps) |
|
Bit Rate |
H.264: 32K ~ 10Mbps |
|
ROI |
Up to 4 areas |
|
Audio |
||
Compression |
G.711a / G.711u/ AAC |
|
Interface |
1/1 channel In/Out(Built-in Mic) |
|
Smart Function |
||
Smart detection |
Tripwire |
|
Intrusion |
||
Abandoned/Missing |
||
Scene Change |
||
Audio detect |
||
Face detect |
||
Network |
Ethernet |
RJ-45 (10/100Base-T) |
|
Wi-Fi |
N/A |
|
Protocol |
IPv4/IPv6, HTTP, HTTPS, SSL, TCP/IP, UDP, UPnP, ICMP, IGMP, SNMP, RTSP, RTP, SMTP, NTP, DHCP, DNS, PPPOE, DDNS, FTP, IP Filter, QoS, Bonjour,802.1x |
|
Compatibility |
ONVIF ,PSIA,CGI |
|
Max. User Access |
20 users |
|
Smart Phone |
iPhone, iPad, Android, Windows Phone |
|
Auxiliary Interface |
||
Memory Slot |
Micro SD card, Max 128GB |
|
RS485 |
1 |
|
Alarm |
2/1 channel In/Out |
|
General |
||
Power Supply |
DC12V/AC24V, PoE (802.3af) |
|
Power Consumption |
< 10W (ABF&ICR on) |
|
Working Environment |
-30°C~+60°C, Less than 95% RH |
|
Ingress Protection |
N/A |
|
Dimensions |
74.1mm×65.5mm×135.4mm |
|
Weight |
0.3Kg |
