Veracity VHW-HWPS-B4 HW Powerstar BASE4
Images are for illustration purpose and may not show the actual product.
Model:
VHW-HWPS-B4
Item #: 1821
Manufacturer: Veracity
MSRP:
$980.00
Our Price:
$629.00
(You save: $351.00)
- Re-use existing coax currently used for analogue cameras
- Replace typical 4-channel video encoders with a full IP system
- Reliably power new IP cameras with POE over coax
- Fully automatic installation - no set-up of EOC* adaptor required
- Simple fast, cost-effective installation, less time on site
| POWER |
|
|
| Unit power |
|
4.5 watts |
| POE Out |
|
IEEE 802.3af (POE) or IEEE 802.3at (POE Plus) up to 25W per channel |
| Power input |
|
57V DC, up to 6A via a 2 pin detachable screw terminal (supplied) |
| |
|
or a 2 pin Micro-Fit power connector |
| HIGHWIRE INTERFACE |
|
| Connector type |
|
BNC 75 Ohm x 4 |
| Cable type |
|
Any 75 Ohm coaxial (other impedances supported) |
| Range |
|
Up to 300m [1000ft] on RG59 or 500 metres [1640 feet] on RG11 at full rate |
| Bandwidth |
|
200 Mbps (total up + down) x 4 |
| |
|
|
| ETHERNET INTERFACE |
|
| Connector type |
|
RJ45 |
| Cable type |
|
Patch or crossover, auto-detected |
| Rate |
|
Gigabit Ethernet |
| |
|
|
| LEDS |
|
|
| Status indicators |
|
HIGHWIRE coax link |
| |
|
Ethernet link/activity (BASE) |
| |
|
POE-over-coax |
| |
|
See Quickstart Guide for LED indicator table and diagnostics |
| PHYSICAL/ENVIRONMENTAL |
| Dimensions |
|
L 173mm (including BNC connectors) W 110mm H22mm |
| Weight |
|
356g [12.5oz] |
| Operating temperature |
0ºC to 40ºC [32ºF to 104ºF] |
| Relative humidity |
|
85% non-condensing |
| Compliance |
|
FCC, CE, RoHS, REACH |
