| Signal System | NTSC |
| Image Sensor | 1/3" Color CMOS |
| Effective Pixels(HxV) | 1280(H) x 720(V) |
| S/N Ratio | > 48dB |
| Clock Frequency | NTSC: 28.636 / PAL: 28.375 |
| Scanning System | 2:1 Interface |
| Minimum Illumination | 0 Lux (with IR LED ON) |
| Synchronous System | Internal, Negative Sync. |
| Auto Electronic Shutter | NTSC: 1/60s~1/100,000s PAL: 1/50s~1/100,000s |
| Gamma Characteristic | 0.45 |
| IR Distance | 98ft (with 36 Unit Infrared LED) |
| IR Status | Under 10 Lux by CDS |
| IR Power On | CDS Auto Control |
| Video Output | 1 Vpp, 75 Ω |
| Auto Gain Control | AUTO |
| Power/Current | 12VDC (+/-10%) / 400mA |
| Lens | 2.8-12mm |
| Dimensions | 4.7in.(Ø) x 4in.(h) |
| Weight | 1.34 |
| Storage Temperature | -22°F ~ 140°F |
| Operating Temperature | 14°F ~ 113°F |
