| Image Sensor | 1/3” Progressive Scan CMOS |
| Effective Pixels | 1280(H) x 720(V) |
| Min. Illumination | 0.01 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Time | 1/25(1/30) s to 1/50,000 s |
| Lens | 3.6mm Angle of View: 76.88°(3.6mm), 99.73°(2.8mm), 50.1°(6mm) |
| Lens Mount | M12 |
| Angle Adjustment | Pan: 0 - 360°, Tilt: 0 - 90°, Rotation: 0 - 360° |
| Day & Night | ICR |
| Synchronization | Internal synchronization |
| Video Frame Rate | 25 fps (PAL) / 30 fps (NTSC) |
| HD Video Output | 1 Analog HD output |
| S/N Ratio | More than 52dB |
| Working Temperature/Humidity | -40 °C - 60 °C (-40 °F - 140 °F) Humidity 90% or less (non-condensing) |
| Power Supply | DC 12V |
| Power Consumption | Max. 3.5W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 20m |
| Dimensions | ø70x149.5mm (ø2.76”x5.89”) |
| Weight | 360g (0.79lb) |
