| Resolution | HD-SDI(1080P, 720P) / 1000 TV LINE OVER |
| Sensor | 1/2.9" SONY CMOS |
| Total Pixels | 2000(H) × 1241(V) = 2,482,000 |
| Effective Pixels | 1944(H) × 1092(V) = 2,122,648 |
| Scanning System | PROGRESSIVE |
| S/N (Y signal) | More than 52dB (AGC Off) |
| Video Output | SMPTE292M (HD-SDI) |
| Min.Illumination | 1 Lux at F1.2 / 0.1 Lux (B/W) |
| White Balance | AUTO |
| Shutter | AUTO (1/30 sec ~ 1/60,000 sec) |
| Brightness | ADJUSTABLE (0~20 STEP) |
| DNR | HIGH |
| DAY & NIGHT | EXTERN |
| LANGUAGE | ENGLISH |
| OPERATING TEMPERATURE / HUMIDITY | -10°C ~ +50°C / 30% ~ 80% RH |
| STORAGE TEMPERATURE / HUMIDITY | -20°C ~ +60°C / 20% ~ 90% RH |
| POWER | DC 12V |
| SIGNAL TRANSMISSION | The distant difference is occurred according to cable option and other circumstances. (based on RG59: 100M) |
