| System |
| Operating System |
Embedded LINUX |
| Video & Audio |
| IP Camera Input |
32 channel |
| Two-way Talk |
1 channel Input, 1 channel Output, BNC |
| Display |
| Interface |
1 HDMI, 1 VGA, 1 BNC |
| Resolution |
800×600;1024×768;1280×1024;1440×900;1920×1080 |
| Display Split |
1/4/9/16/32 |
| OSD |
Camera title, Time, Video loss, Camera lock, Motion detection, Recording |
| Recording |
| Compression |
H.264 (High Profile@Level4.2) / MPEG-4 |
| Resolution |
5MP(2560×1920) / 3MP(2048×1536) / 1080P(1920×1080) / 720P(1280×720) / D1 (704×576/704×480) |
| Record Rate |
Max 22CH@1080P or 22CH@720P or 32CH@D1 |
| Record Mode |
Manual, Schedule(Regular(Continuous), MD, Alarm), Stop |
| Record Interval |
1~120 min (default: 60 min), Pre-record: 1~30 sec, Post-record: 10~300 sec |
| Video Detection & Alarm |
| Trigger Events |
Recording, Alarm, Video Push, Email, Buzzer |
| Video Detection |
Motion Detection,Video Loss,HDD Loss |
| Alarm Input |
16 channel |
| Relay Output |
3 channel |
| Playback & Backup |
| Sync Playback |
1/4/8/16 |
| Search Mode |
Time/Date, Alarm, MD & Exact search (accurate to second) |
| Playback Functions |
Play, Pause, Stop, Rewind, Fast play, Slow play, Next file, Previous file, Next camera, Previous camera, Full screen, Repeat, Shuffle, Backup selection, Digital zoom |
| Backup Mode |
USB Device / Network |
| Network |
| Ethernet |
RJ-45 port (10/100M/1000M) |
| Network Functions |
HTTP, IPv4/IPv6, TCP/IP, UPNP, DHCP, DNS, PPPOE, DDNS |
| Max.User Access |
10 users |
| Mobile Phone |
IPhone, IPad, Android |
| Storage |
| Internal HDD |
4 SATA ports, up to 3TB |
| Auxiliary Interface |
| USB Interface |
3 ports (1 Rear), USB2.0 |
| RS232 |
Yes |
| RS485 |
1 port, For PTZ control |
| General |
| Power Supply |
NVR:DC12V/4A |
| Power Consumption |
20W(without HDD) |
| Working Environment |
-10 ~+55°C / 10~90%RH / 86~106kpa |
| Dimension(W×D×H) |
1U,375×378×65(mm) |
