SYSTEM
|
|
|
Video System
|
NTSC
|
|
IP Camera
|
8ch PoE
|
|
Video Output
|
VGA/HDMI (upto 1920x1080)
|
|
Audio Input / Output
|
IN : 4/8ch (from IP CAM) + 1ch (SET for Two way audio)
OUT : 1ch (SET) |
|
Audio Input Level
|
0.5~1.4 Vp-p @ 20K Ohm
|
|
Sensor Input / Output
|
4 input / 1 relay output
|
|
External Port
|
RS-232 / RS485
|
|
USB Port
|
2 Ports (Front / Rear)
|
|
Control
|
IR Remote Control, Mouse, Client S/W
|
|
RECORDING
|
|
|
CODEC
|
H.264
|
|
Throughput(Bit Rate)
|
Max. 40 Mbps
|
|
Maximum Rate & Resolution
|
Max. 200 / 240 fps @ 1080P
|
|
Record Mode
|
Manual, Schedule, Event (motion/sensor)
|
|
Quality
|
Super, High, Middle, Low (4levels)
|
|
Pre/Post Recording
|
~5sec / ~300sec
|
|
Motion Detection
|
8 × 8 Grids / 20 Senssitivity Levels
|
|
PLAYBACK
|
|
|
Search Mode
|
Calendar, Time, Event, Thumb-nail, Instant Playback
|
|
Playback Speed
|
1× ~ 16× FF/REW, STEP
|
|
STORAGE
|
|
|
HDD Support
|
2 internal SATA HDDs (Up to 6TB)
|
|
External Storage
|
e-SATA (1 port) / USB (2 port)
|
|
Backup device
|
USB-DVD±RW / USB flash drive / Network
|
|
OSD
|
|
|
Display Division
|
1, 4, 6, 7, 8, 9
|
|
Title
|
Multi languages / 12 characters
|
|
Digital Zoom
|
2×, 4×, 8×
|
|
NETWORK
|
|
|
CODEC
|
H.264 / JPEG
|
|
Accounts
|
1 Admin + 10 Users
|
|
Client Software
|
EMS 2.0 / IE (active-X) / Mac PC / Mobile Phone
|
|
Remote Notification
|
Email message, PUSH Service(Smart Phone)
|
|
Service
|
TCP/IP, SMTP, DHCP, DDNS, UPnP
|
|
OTHER
|
|
|
Firmware Update
|
USB Flash Drive / Network
|
|
Daylight Saving
|
YES
|
|
Power Recovery
|
Auto Recovery
|
|
Log
|
Event log / System log
|
|
Watchdog
|
Software / Hardware watchdog
|
|
Dimension
|
38 × 34 × 7 (CM) / 15 × 13 × 2.7 (Inch)
|
|
Power Source
|
12V 5A Adapter
|
|
48V 2A Adapter(POE)
|
|
|
Operation Environment
|
30 ~ 80% RH, 5°C ~ 40°C (41°F ~ 104°F)
|
