| Camera | |
| Image Sensor | 1/3" CMOS |
| Image Size | 2688 × 1520 |
| Electronic Shutter | 1 / 25 s ~ 1 / 100000 s |
| Min. Illumination | 0.05 lux @F1.2, AGC ON; 0 lux with IR Color : 0.05 lux @F1.2, AGC ON; B / W : 0.01 lux @F1.2, AGC ON |
| Lens | 2.8 ~ 12 mm @F1.4 |
| Lens Mount | CS and Φ14 optional |
| Angle Adjustment | Pan : 0°~360°, Tilt : 0°~77°, Rotation : 0°~360° |
| Image | |
| Resolution | 4MP ( 2560×1440 ), 3MP ( 2304×1296 ), 1080P ( 1920×1080 ), 720P ( 1280×720 ), D1, CIF, 480×240 |
| Main Stream | 60Hz : 4MP ( 1 ~ 30fps ) / 3MP( 1 ~ 30fps ) / 1080P( 1 ~ 30fps ) / 720P( 1 ~ 30fps ) 50Hz : 4MP ( 1 ~ 25fps ) / 3MP( 1 ~ 25fps ) / 1080P( 1 ~ 25fps ) / 720P( 1 ~ 25fps ) |
| Bit Rate | 64 Kbps ~ 10 Mbps |
| Encode Mode | VBR / CBR |
| Quality | Five levels under VBR; Freely adjustable under CBR |
| Image Settings | ROI, Saturation, Brightness, Chroma, Contrast, Wide Dynamic, Sharpen, NR,etc. adjustable through client software or web browser |
| Interfaces | |
| Network | RJ45 |
| Audio | MIC IN × 1, MIC OUT × 1 |
| Video Output | CVBS video output ( BNC × 1 ) |
| Storage Card | Support TF card, up to 64GB |
| RS485 | Yes |
| Alarm Input | 1 CH |
| Alarm Output | 1 CH |
| Functions | |
| Remote Monitoring | IE browsing,CMS remote control |
| Online Connection | Support simultaneous monitoring for up to 10 users; Support multi-stream real time transmission |
| Protocol | TCP / IP, UDP, DHCP, NTP, RTSP, PPPoE, DDNS, SMTP, FTP |
| Storage | TF card local storage, network remote storage |
| Smart Alarm | Motion Alarm, sensor alarm |
| Day & Night | ICR |
| PTZ | RS485 × 1 |
| PoE | Yes |
| Number of IR LED | 30 IR |
| Water-proof | IP66 |
| Others | |
| Power Supply | DC12V / PoE |
| Power Consumption | < 2.5W |
| IR Consumption ON | < 5W |
| Operating Environment | - 20 °C ~ 50 °C,10 % ~ 90 % humidity |
| Dimensions ( mm ) | Φ150 × 114 |
