| Video | |
| Camera input | 4 POE |
| Technology | ONVIF 2.3, RTSP, dual stream |
| # of IP Camera | 4 |
| Output | 1 HDMI (Main Display) 1 VGA (Main Display) |
| Other I/O | |
| Audio input | 1 RCA |
| Audio Output | 1 RCA |
| Sensor In | 4 (NC, NO selectable) |
| Alarm out | 1 relay |
| Operating System | Embedded Linux OS |
| Display | |
| Speed | Real Time |
| Resolution (Pixel) | 1280×1024, 1280×720, 1920×1080, 3840×2160(HDMI only) |
| Split screen | 1,4 |
| Main IPC | |
| Resolution (Pixel) / fps | main: upto 8MP@ 30 dual: upto 960×540 |
| Total Bitrate | 120Mbps |
| Channel Bitrate | 30 Mbps |
| Playback | |
| Display | 1,4 |
| Search mode | Calendar, Event ,POS , Panorama, Thumbnail |
| Fast/Slow speed | Normal, REW & FF [recorded speed ×2, ×4, ×8,×16,×32,×64,×1/2,×1/4], Frame to frame, Pause |
| Other | |
| Backup device | External HDD, CD&DVD-RW, Network, Thumb Drive |
| Network Interface | Gigabit Ethernet |
| The number of HDD | 2 SATA + 1 eSATA (upto 12 bays, No capacity limit ; 6TB or more) |
| Power Consumption | 96W (48V) |
| Operating Temperature | 5 ~40ºC(41~104ºF) |
| Relative Humidity | Maximum 80% non-condensing |
| Dimension | 380(W)×340(D)×50(H) mm |
