| Sensor | 1/3" 4.2Mega progressive scan CMOS |
| Min.illumination | Colour:0.05Lux/F1.2; 0Lux/F1.2(IR ON) |
| Lens | 3.6mm M12 lens |
| IR distance | 1PC IR Array / Up to 100ft |
| Electronic shutter | Auto(1/10s-1/10000s Adjustable) |
| Day/Night | Auto/Color / B&W (IR_CUT) |
| Noise Reduction | 2D/3D Digital Noise Reduction |
| Anti-fog | Support |
| WDR | Digital WDR, Real WDR |
| Image Adjustment | Sharpness,Brightness,Saturation,Contrast Adjustable |
| Video Encoding | H.264, H.265 |
| Encoding Type | H.265:MainProfile H.264:High Profile/Main Profile/BaseLine Profile |
| Record Resolution | Main Stream: 2560×1440@20fps Sub Stream: 704×576@20fps Third Stream:1280×720@15fps |
| Video Bitrate Control | Support VBR/CBR |
| Video Bitrate Range | 32Kbps ~ 8Mbps |
| Reset Button | Front set reset button |
| Network Interface | RJ45 10M/100M adaptive Ethernet interface |
| Motion Detection | Multiple detection zones, variable sensitivity levels |
| Privacy Masking | Four zones for privacy masking |
| Snapshot | JPEG capture,capture resolution is the max coding resolution |
| Security Features | Support password protection, watermarking features |
| Text Overlay | Support (Channel name and time title) |
| Alarm | Support network anomaly,mask alarm and etc. |
| Intelligent Function | Support line-crossing detection |
| Mobile APP. | IOS, Andriod |
| Network Function | TCP/IP / UDP / HTTP / IGMP / ICMP / DHCP / RTP/RTSP / DNS / DDNS / FTP / NTP / PPPOE / UPNP / SMTP / SNMP |
| Protocol | Support ONVIF and CGI protocol |
| Protection Grade | IP66 |
| PoE | Support |
| Power | DC 12V |
| Operation Temperature | −10°C ~ +60°C |
| Operation humidity | 10%~90% |
| Power supply | 3W MAX |
| Dimensions | 122×93(mm) |
| Weight | 390g |
