| Camera | |
| Image Sensor | 1/3" CMOS |
| Signal System | NTSC/PAL |
| Effective Pixels | 1956(H)*1266(V) |
| Min. Illumination | 0.01 Lux, 0 Lux with IR |
| Shutter Speed | 1/30(1/25) s to 1/50,000 s |
| Lens | Motorized Lens: 5-50mm |
| Day & Night | ICR |
| Synchronization | Internal |
| Video Frame Rate | 1080p@30fps/1080p@25fps |
| HD Video Output | 1 HD-TVI Output |
| S/N Ratio | More than 62dB |
| Menu | |
| Camera ID | On/Off (15 characters, position programmable) |
| AGC | Support |
| D/N Mode | Color/BW/EXT |
| White Balance | ATW/AWC-SET/Manual |
| Privacy Mask | On/Off, Maximum 8 zones |
| Motion Detection | On/Off, Maximum 4 zones |
| Language | English/Simplified Chinese/Traditional Chinese |
| Function | True WDR, HLC, 3D DNR, Digital zoom, Slow shutter, Mirror, Defog, Defect pixel correction, SMART D-ZOOM |
| General | |
| Working Temperature /Humidity |
-40 °F - 140 °F (-40°C - 60 °C) Humidity 90% or less (non-condensing) |
| Power Supply | DC 12V, AC 24V |
| Power Consumption | Max. 20W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 360ft (110m) |
| Dimension | 12.3”×4.0”×4.2” (313.5×100.8 × 107.3mm) |
| Weight | 3.7lb(1700g) |
