| Camera | |
| Image Sensor | 1/3" Sensor |
| Signal System | NTSC/PAL |
| Effective Pixels | 1305(H)*977(V) |
| Min. Illumination | Low Lux |
| Shutter Speed | 1/30(1/25) s to 1/50,000 s |
| Lens | 6-22mm, FoV 29.3° / -92° |
| Day & Night | Color Mode |
| Synchronization | Internal |
| Video Frame Rate | 720p@30fps/720p@25fps |
| HD Video Output | 1 Analog HD Output |
| S/N Ratio | More than 62dB |
| Menu | |
| AGC | Low/Medium/High/Off |
| Color/BW | Color Mode |
| White Balance | Auto/ Manual |
| Privacy Mask | On/Off, maximum 8 zones |
| Motion Detection | On/Off, maximum 4 zones |
| Exposure Mode | High light compensation |
| 3D DNR | Low/Medium/High/Off |
| Language | Chinese/English |
| Functions | Contrast, Sharpness, Saturation, Mirror, Digital Zoom |
| White Light Control | On/Off/1-5 level adjustable |
| General | |
| Working Temperature /Humidity |
-40 °F - 140 °F (-40°C - 60 °C) Humidity 90% or less (non-condensing) |
| Power Supply | DC 12V |
| Power Consumption | Max. 5W |
| Weather Proof Ratings | IP66 |
| Flux LED | Up to 131ft (40m) |
| Dimension | 5.3” ×4.7”×11.5”( 134.0×116.0×293.0mm) |
| Weight | 1.6lb (700g) |
