| Camera | |
| Image Sensor | 1 / 2.7” Sensor |
| Signal System | NTSC/PAL(Euro Version) |
| Effective Pixels | 1930(H)*1088(V) |
| Min. Illumination | 0.1 Lux @(F1.2,AGC ON), 0 Lux with IR |
| Shutter Speed | NTSC:1/30 s to 1/50,000 s PAL:1/25 s to 1/50,000 s |
|
Lens
|
3.6mm Angle of View: 90° |
| Day & Night | ICR |
| Synchronization | Internal synchronization |
| S/N Ratio | More than 52dB |
| General | |
| Working Temperature /Humidity |
-40 °F - 140 °F (-40 °C - 60 °C) |
| Humidity 90% or less (non-condensing) | |
| Power Supply | 12V DC |
| Power Consumption | Max. 3W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 65ft |
| Dimension | φ3.5” ×2.3”(φ89.6×59.1mm) |
| Weight | 0.5lb(240g) |
