| Camera | |
| Image Sensor | 1/2,9" CMOS |
| Signal System | NTSC/PAL |
| Effective Pixels | 1930(H)*1088(V) |
| Min. Illumination | 0.01 Lux, Lux with IR |
| Shutter Speed | 1/30(1/25) s to 1/50,000 s |
| Lens | 2.8mm Angle of View: 105.8° |
| Day & Night | ICR |
| Synchronization | Internal |
| Video Frame Rate | 1080p@30fps/1080p@25fps |
| HD Video Output | 1 HD-TVI Output |
| S/N Ratio | More than 52dB |
| Menu | |
| AGC | Support |
| D/N Mode | Color/BW/EXT |
| White Balance | Auto/Manual |
| BLC | Support |
| Language | English/Chinese |
| Function | Digital noise reduction, Mirror |
| General | |
| Working Temperature /Humidity |
-40°F - 140°F (-40°C - 60°C) Humidity 80% or less (non-condensing) |
| Power Supply | DC 12V |
| Power Consumption | Max. 3.5W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 131ft (40m) |
| Dimensions | 5.0" x 4.0" (126.7 x 102.1mm( |
| Weight | 1.1lb (500g) |
