| Camera | |
| Image Sensor |
1 / 2.7” Sensor
|
| Signal System |
NTSC/PAL(Euro Version)
|
| Effective Pixels |
1930(H)*1088(V)
|
| Min. Illumination |
0.1 Lux @(F1.2,AGC ON), 0 Lux with IR
|
| Shutter Speed |
NTSC:1/30 s(PAL:1/25 s) to 1/50,000s
|
| Lens |
3.6mm
|
| Day & Night |
Angle of View: 90°
|
| Synchronization |
ICR
|
| Video Frame Rate | Internal synchronization |
| HD Video Output | NTSC: 1080p@30fps/PAL: 1080p@25fps |
| HD Video Output | 1 HD-TVI Output |
| S/N Ratio | More than 52dB |
| Menu | |
| Camera ID | On/Off (0-255) |
| AGC | Support |
| D/N Mode | Color/BW/Auto/EXT |
| White Balance | Auto/User/Push/8000K/6000K/4200K/3200K/HOLD |
| Privacy Mask | On/Off, Maximum 2 zones |
| Motion Detection | On/Off |
| BLC | Support |
| Anti-Flicker | On/Off |
| Language | English, Chinese |
| Function | Mirror |
| General | |
| Working Temperature /Humidity |
-40 °F - 140°F (-40 °C - 60°C)
Humidity 90% or less (non-condensing)
|
| Power Supply | 12V DC |
| Power Consumption | Max. 3W |
| Weather Proof Ratings | IP66 |
| IR Range | Up to 131ft (40m) |
| Dimensions | φ5.0"x4.0" (φ126.7 x 102.1mm) |
| Weight | 1.1lb (500g) |
