| Video / Audio input | |||
| Video compression | H.264 | ||
| HD-TVI video input | 8-ch | ||
| Video input interface | BNC (1.0 Vp-p, 75 Ω), PAL / NTSC self-adaptive | ||
| IP input | 2ch(1080p@30fps) | ||
| Audio compression | G.711u | ||
| Audio input | 1-ch, RCA (2.0 Vp-p, 1 kΩ) | ||
| Two-way audio input | 1-ch, RCA (2.0 Vp-p, 1 kΩ) | ||
| Video / Audio output | |||
| HDMI/VGA output | 1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz | ||
| Encoding resolution | Main stream: 1080P(non-real-time) / 720P / VGA / WD1 / 4CIF / CIF | ||
| Sub-stream: WD1(non-real-time) / 4CIF(non-real-time) / CIF / QCIF / QVGA | |||
| Frame rate | Main stream: 1/16 fps ~ Real time frame rate | ||
| Sub-stream: 1/16 fps ~ Real time frame rate | |||
| Video bit rate | 32 Kbps-4 Mbps | ||
| Audio output | 1-ch, RCA (Linear, 1 kΩ) | ||
| Audio bit rate | 64 Kbps | ||
| Dual-stream | Support | ||
| Stream type | Video, Video & Audio | ||
| Synchronous playback | 8-ch | ||
| Playback resolution | 1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF | ||
| Network | |||
| Remote connection | 128 | ||
| Network protocols | TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS | ||
| Hard disk | |||
| SATA | 1 SATA interface | ||
| Capacity | Up to 6TB capacity for each disk | External interface | |
| Network interface | 1:10M / 100M self-adaptive Ethernet interface | ||
| Serial interface | 1; standard RS-485 serial interface, half-duplex | ||
| USB port | 2 × USB2.0 | ||
| Alarm in/out | 8/4 | ||
| General | |||
| Power supply | 12V DC | ||
| Power Consumption | ≤ 20 W | ||
| Working temperature | -10 °C~+55°C(14°F ~ 131 °F) | ||
| Working humidity | 10% ~ 90% | ||
| Dimension |
315 × 230 × 45 mm |
||
| Weight | ≤ 1.5 kg (3.3 lb) | ||
