| Video / Audio input |
| Video compression |
H.264 |
| HD-TVI video input |
16 CH |
| Video input interface |
BNC interface (1.0Vp-p, 75 Ω) |
| IP input |
16CH (1080p@30fps) |
| Supported camera types |
720P25, 720P30, 720P50, 720P60, 1080P25, 1080P30, CVBS |
| Audio compression |
G.711u |
| Audio input |
4-ch, RCA (2.0 Vp-p, 1 kΩ) |
| Two-way audio input |
1-ch, RCA (2.0 Vp-p, 1 kΩ) |
| Video / Audio output |
| HDMI/VGA output |
1920 × 1080 / 60 Hz,1280 × 1024 / 60 Hz, 1280 × 720 / 60 Hz, 1024 × 768 / 60 Hz |
| CVBS output |
1-ch, BNC (1.0 Vp-p, 75 Ω), resolution: PAL: 704 × 576, NTSC: 704 × 480 |
| Encoding resolution |
Main stream: 1080P / 720P / VGA / 4CIF / CIF |
| Sub-stream: WD1(non-real-time) / 4CIF(non-real-time) / CIF / QCIF / QVGA |
| Frame rate |
Main stream: 1/16 fps ~ Real time frame rate |
| Sub-stream: 1/16 fps ~ Real time frame rate |
| Video bit rate |
32 Kbps-10 Mbps |
| Audio output |
2-ch, RCA (Linear, 1KΩ, for VGA output and CVBS output respectively) |
| Audio bit rate |
64 Kbps |
| Dual-stream |
Support |
| Stream type |
Video, Video & Audio |
| Synchronous playback |
16 CH |
| Playback resolution |
1080P / 720P / VGA / WD1 / 4CIF / CIF / QVGA / QCIF |
| Network |
| Remote connection |
128 |
| Network protocols |
TCP/IP, PPPoE, DHCP, DNS, DDNS, NTP, SADP, SMTP, SNMP, NFS, iSCSI, UPnP™, HTTPS |
| Hard disk |
| SATA |
4 SATA interfaces for 4 HDDs; 1 eSATA interface |
| Capacity |
Up to 6TB capacity for each disk |
| External interface |
| Network interface |
1; 10M / 100M / 1000M self-adaptive Ethernet interface |
| Serial interface |
RS-232, RS-485, Keyboard |
| USB port |
3 × USB2.0 |
| Alarm in / out |
16 / 4 |
| General |
| Power supply |
100 ~ 240VAC, 47 ~ 63HZ |
| Power Consumption |
≤ 55 W |
| Working temperature |
-10 °C~+55°C(14°F ~ 131 °F) |
| Working humidity |
10% ~ 90% |
| Dimension |
445 × 390 × 70 mm (17.5'' × 15.3'' × 2.7'') |
| Weight |
≤5Kg (11.0lb)(without hard disks) |
