| Camera | |
| Image Sensor | 1/2.8’’ sensor |
| Effective Pixel | 2230K pixels |
| Min. Illumination | Color: 0.05Lux@F1.6, AGC ON; B/W: 0.01Lux@F1.6, AGC ON) |
| White Balance | Auto / Manual /ATW/Indoor/Outdoor/Daylight lamp/Sodium lamp |
| AGC | Auto / Manual |
| S / N Ratio | ≥ 52dB |
| Digital Noise Reduction | 3D DNR |
| Backlight compensation | BLC |
| Wide Dynamic Range | 128X Digital WDR |
| Shutter Speed | 1 ~ 1/10,000s |
| Day & Night | IR Cut Filter |
| Focus Mode | Auto / Semiautomatic / Manual |
| Lens | |
| Focal Length | 4.3 ~ 129mm, 30x |
| Zoom Speed | Approx 3s(Optical Wide-Tele) |
| Angle of View | 65.1 ~2.34 degree (Wide-Tele) |
| Min. Working Distance | 10 ~ 1500mm(Wide-Tele) |
| Aperture Range | F1.6 ~F5.0 |
| Pan and Tilt | |
| Pan / Tilt Range | Pan: 360° endless; Tilt: -5° ~ 90° (Auto Flip ) |
| Pan / Tilt Speed | Pan Manual Speed: 0.1° ~ 250°/s, Pan Preset Speed: 300°/s Tilt Manual Speed: 0.1° ~ 150°/s, Tilt Preset Speed: 200°/s |
| Proportional Zoom | Rotation speed can be adjusted automatically according to zoom multiples |
| Number of Preset | 256 |
| Park action | Pattern/Pan scan/Tilt scan/Frame scan/Panorama scan/Random scan |
| Patrol | 8 patrols, up to 32 presets per patrol |
| Power-off Memory | Support |
| Input/ Output | |
| Audio Input | Audio input (Line input), 2 ~ 2.4V[p-p]; output impedance: 1KΩ±10% |
| Audio Output | Line level, impedance: 600Ω |
| Network | |
| Ethernet | 10Base-T / 100Base-TX, RJ45 connector |
| Max. Image Resolution | 1920×1080 |
| Frame Rate | 60Hz: 30 fps (1920×1080),30 fps (1280×960) , 30 fps (1280×720) 50Hz: 25 fps (1920×1080),25 fps (1280×960) , 25 fps (1280×720) |
| Image Compression | H.264/MPEG4 |
| Audio Compression | G.711u /G.711a /G.726 |
| Protocols | IPv4/IPv6, HTTP, HTTPS, 802.1x, Qos, FTP, SMTP, UPnP, SNMP, DNS, DDNS, NTP, RTSP, RTP, TCP, UDP, IGMP, ICMP, DHCP, PPPoE |
| Simultaneous Live View | Up to 6 |
| Streams | Dual Streams |
| Mini SD Memory Card | Micro SD Slot, up to 32GB |
| User/Host Level | Up to 32 users, 3 Levels: Administrator, Camera control, Live view only |
| Security Measures | User authentication (ID and PW), Host authentication (MAC address), IP address filtering |
| Integration | |
| Application programming | Open-ended API, support Onvif, PSIA and CGI |
| Web Browser | IE 7, IE 8, IE 9, Chrome 8 +, Firefox 3.5 +, Safari 5 + |
| General | |
| Working Temperature /Humidity |
-30 °C ~ 65°C(-22°F ~ 149°F) 90% or less |
| Power Supply | 24 VAC / PoE+; |
| Power Consumption | Max. 22W |
| Ingress protection level | IP66 standard TVS 4,000V lightning protection, surge protection and voltage transient protection |
| Impact Protection | IEC60068-275Eh, 20J; EN50102, up to IK10 |
| Dimension | Φ220×305mm (Φ8.66”×12.02” without bracket) |
| Weight | 5kg(11.02Ibs without bracket) |
