Camera |
Image Sensor |
1/3 " Progressive Scan CMOS |
Min. Illumination |
Color: 0.01 Lux @ (F1.2, AGC ON), 0.028 Lux @ (F2.0, AGC ON) B/W: 0.001 Lux @ (F1.2, AGC ON), 0.0028 Lux @ (F2.0, AGC ON) |
Shutter Speed |
1/1s ~ 1/100,000s |
Slow Shutter |
Support |
Lens |
2.8mm/F2.0, horizontal FoV: 92.5º |
Day & Night |
Electronic |
DNR |
3D DNR |
Wide Dynamic Range |
True 120dB Wide Dynamic Range |
Lens Cable Length |
2 meters |
Compression Standard |
Video Compression |
H.264 / MJPEG/MPEG4 |
H.264 Type |
Baseline Profile / Main Profile / High Profile |
Video bit Rate |
32 Kbps ~ 16 Mbps |
Audio Compression |
G.711/G.722.1/G.726/MP2L2 |
Audio Bit Rate |
64Kbps(G.711) / 16Kbps(G.722.1) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
Image |
Max. Resolution |
1280 x 960 |
Frame Rate (Main Stream) |
60Hz: 30fps (1280 x 960), (1280 x 720) 50Hz: 25fps(1280 x 960), (1280 x 720) |
Frame Rate (Sub Stream) |
25/30fps (VGA, 4CIF, CIF) |
Frame Rate (Third Stream) |
60Hz: 30fps (1280 x 960) 50Hz: 25fps(1280 x 960) |
Image Setting |
Rotate Mode, Saturation, Brightness, Contrast, Sharpness adjustable by client software or web browser |
BLC |
Support, zone configurable |
ROI Codec |
Support |
Defog |
Yes |
HLC |
Yes |
EIS |
Yes |
Day/Night Switch |
Auto/Schedule/Triggered by Alarm In |
Picture Overlay |
LOGO picture can be overlaid on video with 128x128 24bit bmp format |
Interface |
Audio Interface |
1 x 3.5mm audio input (Mic in / Line in) / output external interface |
Communication Interface |
1 x RJ45 10M/100M Ethernet interface/1 RS232/1 RS-485 |
Alarm I/O |
1/1 |
Network |
Network Storage |
NAS (NFS,SMB/CIFS) |
Alarm Trigger |
Intrusion detection, audio exception detection, defocus detection, motion detection, face detection, dynamic analysis, tampering alarm, network disconnect, IP address conflicts, storage full, storage error |
Protocols |
TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTP, RTSP, RTCP, PPPoE, NTP, UPnP, SMTP, SNMP, IGMP, 802.1X, QoS, IPv6, Bonjour |
Standard |
ONVIF, PSIA, CGI, ISAPI |
Common Features |
Reset, flickerless, three streams, heartbeat, mirror, password protection, video masking, watermark, anonymous login, IP address filtering |
People Counting |
People Counting |
People entering and exiting data can be accounted, displayed and exported People counting data can be displayed on screen in real time and exported day/week/month/ year excel chart (with SD card/NAS/Storage Server/Platform) |
General |
Working Temperature/ Humidity |
-22 °F ~ 140°F (-30 °C ~ 60 °C)/Humidity 95% or less (non-condensing) |
Power Supply |
DC12V ± 10% |
Power Consumption |
Max. 6.5W |
Dimensions |
Main unit: 4.2” x 3.1” x 1.3”(107.6 x 78 x 33.5mm) Lens: 1.9” x 1.2” x 1.2”(48.7 x 30.7 x 31.5mm) Lens cover : Φ3.7” x 1.2”(Φ95 x 31.5mm) |
Weight |
1.4 lbs (615 g)
|
|
