| Camera | |
| Signal System | Progressive image processing |
| Scaning System | 16:9 Progressive |
| Image Sensor | 1/3" Progerssive CMOS Sensor |
| Sync. System | Internal |
| Effective Pixels Number | 1920(H) x 1080(V) 2.0 Mega |
| Horizontal Resolution | 1100 TV Lines |
| Video Output Level | Select NTSC/PAL 1.0Vp-p (BNC 75Ω, composite) |
| Lens Mount | CS Mount |
| Day & Night System | ICR (CDS Type) |
| Min. Illumination | 1Lux (Color), 0.1Lux (B/W), 0.05Lux (B/W, DSS On) |
| Back Light Compensation | On/Off |
| Flickerless | On/Off |
| White Balance | Auto/Manual |
| Exposure | Auto/Manual |
| Function | B/W |
| Elec. Shutter Speed | NTSC : 1/7.5~1/8,000 (21 Step) PAL : 1/7.5~1/8,000 (21 Step) |
| Video / Audio | |
| Compression | H.264 / MJPEG |
| Frame Rate | Dual Mode : H.264(30fps) / MJPEG(30fps) |
| Resolution | Full HD(1920x1080), SXGA(1280x1024), 720P(1280x720), D1(720x480/720x576), VGA(640x480), CIF(352x240/352x288) |
| Audio | Two-way (full duplex / ADPCM G.726) |
| Network | |
| Protocol | IPv4, HTTP, TCP, RTSP, RTP, RTCP, UDP, SMTP, FTP, ICMP, DHCP, UPnP, Bonjour, ARP, DNS, DynDNS |
| Supported DDNS | 1.CNB DDNS 2.DynDNS.org 3.Reference code with SDK |
| LAN Interface | Ehternet 10/100 Base-T (RJ-45 Type) |
| Suppot PoE | Standard IEEE 802.3af supported |
| Security | |
| Access Level Setup | Multiple user access levels with password protection |
| Network Security | IP Filtering |
| Alarm and Event Managerment | |
| Image Detection | Motion detection (Select 3 Regions - each area) |
| Sensor Detection | Sensor In, Scheduling, Alarm out |
| After Event Process | JPEG Image upload over FTP server / SMTP (E-mail server) |
| Applications | |
| Browser | Internet Explorer 6.0 or higher |
| Monitoring Application | XNVR, CNB CMS and Utility (IP-Installer, etc) |
| Maintenance | |
| System Upgrade | Firmware upgrade over HTTP |
| PTZ control (RS-485) | PTZ Protocol Service (User define update) |
| Mechanical | |
| Operating Temperature | 0℃ ~ 40℃ |
| Power | DC 12V Max. 5W |
| Dimensions/Weight(Net) | 71(W) x 65(H) x 143.9(D)mm, Approx. 366g |
