| Camera | |
| Image Sensor | 1/3” sensor |
| Min. Illumination |
0.07Lux @ (F1.2, AGC ON) ,0 Lux with IR
0.19 Lux @ (F2.0, AGC ON) ,0 Lux with IR
|
| Shutter Time | 1/3s ~ 1/100,000s |
| Lens |
4mm@F2.0
Angle of view: 79°
|
| Lens Mount | M12 |
| Angle Adjustment | Pan:0°- 355°, Tilt: 0° - 75°, Rotation: 0°-355° |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Day & Night | ICR |
| Compression Standard | |
| Video Compression |
H.264 / MJPEG
|
| H.264 Codec Profile |
Main profile
|
| Bit Rate |
32 Kbps ~ 12 Mbps
|
| Dual Stream | Yes |
| Image | |
| Max. Image Resolution |
2048 × 1536
|
| Frame Rate |
60 Hz: 20fps (2048 x 1536), 30fps (1920 × 1080), 30fps (1280 x 720)
50 Hz: 20fps (2048 x 1536), 25fps (1920 × 1080), 25fps (1280 x 720)
|
| Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by cli
ent software or web browser
|
| BLC |
Yes, zone optional
|
| ROI | Support |
| Network | |
| Network Storage |
Local storage: Built-in Micro SD/SDHC/SDXC card slot, up to 64
GB. NAS (Support NFS,SMB/CIFS)
|
| Alarm Trigger |
Intrusion detection, Line crossing detection, Motion detection,
Dynamic Analysis, Tampering alarm, Network disconnect, IP address conflict, Storage full, Storage error
|
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,
PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour
|
| System Compatibility |
ONVIF, PSIA, CGI, ISAPI
|
| Security |
User Authentication, Watermark
|
| Interface | |
| Communication Interface |
1 RJ45 10M / 100M ethernet port
|
| General | |
| Operating Conditions |
-22°F ~ 140°F(-30°C ~ 60°C) humidity 95% or less (non-condensing)
|
| Power Supply |
12 VDC ± 10%, PoE (802.3af)
|
| Power Consumption |
Max. 5W
|
| Impact Protection |
IEC60068-275Eh, 50J; EN50102, up to IK10
|
| Ingress Protection | IP66 |
| IR Range |
Approx 100 ft(About 30m)
|
| Dimensions |
Φ4.4”x3.2”(Φ111.0 × 82.4 mm )
|
| Weight |
1.1lb(500g)
|
