| Model Name | CM7233-S |
| Description | 3.2MP |
| Image Sensor | 1/3” Progressive Scan CMOS |
| Min. Illumination | 0.1 lux, AGC on 0 lux with IR |
| Lens | 2.8 - 12mm |
| Motorized VF Lens | - |
| Day/Night | ICR |
| Video Compression | H.264 / MJPEG |
| Max. Image Resolution | 2048×1536 |
| Frame Rate |
60HZ: 30fps(1920×1080) 50HZ: 25fps(1920×1080) |
| Power Over Ethernet | Yes |
| Motion Detection | Yes |
| On-board Storage | Built-in Micro SD card slot, up to 64 GB |
| Audio Input/Output | 1/1 |
| Alarm Input/Output | 1/1 |
| IR LEDs | 24pcs, Up to 100ft(30m) |
| Other Features | 3D DNR,DWDR,BLC |
| Power Supply | 12V DC / POE(802.3af) |
| Protection | IP66 |
| Certification | UL, cUL, FCC, CE |
| Operating Temperature | -22 °F -140 °F(-30 °C - 60 °C) |
| Product Dimension | Φ5.5" × 3.9"(Φ140.0 × 99.9mm) |
| Product Weight | 1.7lb(0.8Kg) |
