| Camera | |
| Image Sensor | 1/3” sensor |
| Min. Illumination | 0.014 lux @F1.4, AGC on 0 lux with IR |
| Shutter Speed | 1/25s ~ 1/100,000s |
| Lens | 2.8-12 mm @F1.4 |
| Angle of view: 113°-33.8° | |
| Lens Mount | Φ14 |
| Day & Night | ICR |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Backlight compensation | Yes,zone optional |
| Angle adjustment | Pan: 0° - 355°, Tilt: 0° - 75°, Rotation: 0° - 355° |
| Compression Standard | |
| Video Compression | H.264 / MJPEG |
| H.264 codec profile | Main profile |
| Bit Rate | 32 Kbps ~ 16 Mbps |
| Audio compression | G.711/G.726/MP2L2 |
| Audio bit rate | 64Kbps(G.711) / 16Kbps(G.726) / 32-128Kbps(MP2L2) |
| Dual Stream | Yes |
| Image | |
| Max. Resolution | 1920×1080 |
| Frame Rate | 60Hz: 30fps (1920×1080) 50Hz: 25fps (1920×1080) |
| Image Settings | Saturation, brightness, contrast adjustable through client software or web browser |
| ROI | Yes, up to 4 configurable areas |
| Network | |
| Network Storage | NAS |
| Alarm Trigger | Motion detection, Tampering alarm, Network disconnect, IP address confict, Storage full , Storage error |
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP,PPPoE, NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| System compatibility | ONVIF, PSIA, CGI, ISAPI |
| General functionalities | User Authentication, Watermark |
| Interface | |
| Communication Interface | 1 RJ45 10 M / 100 M Ethernet interface |
| On-board Storage | Built-in Micro SD/SDHC/SDXC card slot, up to 64 GB |
| Audio Input/Output | 1/1 |
| Alarm Input/Output | 1/1 |
| General | |
| Working Temperature /Humidity |
-22 °F ~ 140 °F(-30 °C ~ 60 °C ) Humidity 95% or less (non-condensing) |
| Power Supply | DC12V±10% / PoE(802.3af) |
| Power Consumption | Max. 5.5W |
| Impact protection | IEC60068-2-75Eh, 50J; EN50102, up to IK10 |
| Ingress protection level | IP66 |
| IR Range | Up to 100ft(About 30m) |
| Dimension | Φ5.5"×3.9"(Φ140.0 x 99.9mm) |
| Weight | 2.2lbs(1000g) |
