| Camera | |
| Image Sensor | 1/2.8” progressive scan CMOS |
| Min. Illumination | 0.01Lux @(F1.2,AGC ON) 0 Lux with IR |
| Shutter Speed | 1/3s ~ 1/100,000s |
| Lens | 4mm@F2.0 |
| Angle of view: 79° | |
| Lens Mount | M12 |
| Angle adjustment | Horizontal: 0° ~ 360°, vertical: 0° ~ 75°, rotation: 0° ~ 360° |
| Day & Night | ICR |
| Digital Noise Reduction | 3D DNR |
| Wide Dynamic Range | Digital WDR |
| Compression Standard | |
| Video Compression | H.264 / MJPEG |
| Bit Rate | 32 Kbps ~ 8 Mbps |
| Dual stream | Yes |
| Image | |
| Max. Resolution | 1920 x 1080 |
| Frame Rate | 60 Hz: 30 fps (1920 × 1080), 30fps (1280 × 960), 30 fps (1280 x 720) 50 Hz: 25 fps (1920 × 1080), 25 fps (1280 × 960), 25 fps (1280 x 720 |
| Image Settings |
Rotate mode, Saturation, Brightness, Contrast adjustable by client software or web browser |
| BLC | Yes, zone optional |
| ROI | Support |
| Network | |
| Network Storage | NAS (Support NFS, SMB/CIFS) |
| Alarm Trigger | ntrusion detection, Line crossing detection, Motion detection, Dynamic analysis, Tampering alarm, Network disconnect , IP address conflict, Storage exception |
| Protocols |
TCP/IP,ICMP,HTTP,HTTPS,FTP,DHCP,DNS,DDNS,RTP,RTSP,RTCP, PPPoE,NTP,UPnP,SMTP,SNMP,IGMP,802.1X,QoS,IPv6,Bonjour |
| System Compatibility | ONVIF, PSIA, CGI, ISAPI |
| General functionalities |
One-key reset, Flash-prevention, dual stream, heartbeat, mirror, password protection, privacy mask, watermark, IP address filtering, Anonymous access |
| Interface | |
| Communication Interface | 1 RJ45 10M / 100M ethernet port |
| General | |
| Working Temperature /Humidity |
-22°F ~ 140°F(-30°C ~ 60°C ) humidity 95% or less (non-condensing) |
| Power Supply | 12 VDC ± 10%, PoE (802.3af) |
| Power Consumption | Max. 7.5W |
| Ingress Protection Level | IP66 |
| IR Range | About 65 to 100ft(20-30m) |
| Dimension | Φ5.0“× 3.8”(Φ126.7 x 97.2 mm) |
| Weight | 1.3lb(570g) |
