| Video / Audio Input | |
| IP Video Input | 64-ch |
| Two-Way Audio Input | 1-ch, RCA (2.0 Vp-p, 1kΩ) |
| Network | |
| Incoming Bandwidth | 768Mbps |
| Outgoing Bandwidth | 768Mbps |
| Remote connection | 128 |
| Network Protocol | HIKVISION, ACTi, ARECONT, AXIS, BOSCH, BRICKCOM, CANON, HUNT, ONVIF(Version 2.4), PANASONIC, PELCO, PSIA, SAMSUNG,SANYO, SONY, VIVOTEK, ZAVIO |
| HDMI output |
2-ch, resolution: |
| VGA Output |
1-ch, resolution: |
| Audio Output | 1-ch, BNC (Linear, 600 Ω) |
| Decoding | |
| Decoding Format | H.264, MPEG4, M-JPEG |
| Recording Resolution | 8MP/5MP/3MP/1080P/ UXGA/ 720P/ VGA / 4CIF/DCIF/2CIF/CIF/QCIF |
| Synchronous playback | 16-ch |
| Hard disk | |
| SATA | Up to 8 SATA interfaces for 4HDD+1 DVD-R/W, or 8HDDs |
| eSATA | 1 eSATA interface |
| Capacity | Up to 8TB capacity for each HDD |
| Disk array | |
| Array Type | RAID0, RAID1, RAID5, RAID10 |
| Number of Array | 8 |
| Interface | |
| Network Interface | 2 RJ-45 10 /100 /1000 Mbps self-adaptive Ethernet interfaces |
| Serial interface | RS-232, RS-485, RS-485 keyboard |
| USB Port | 2 x USB2.0 + 2 x USB3.0 |
| Alarm In/Out | 16/4 |
| General | |
| Power Supply | 100 ~ 240 VAC, 6.3A, 50 ~ 60Hz |
| Power Consumption | ≤100W |
| Working Temperature | -10°C ~ +55°C (14 °F ~ 131 °F) |
| Working humidity | 10% ~ 90% |
| Dimension | 445 × 470 × 90 mm (17.52" ×18.5"× 3.54") |
| Weight | ≤ 8 kg (17.64 lb) ( without hard disk or DVD-R/W ) |
