| Image Sensor | 1 / 3 ” Mega Pixel Sensor |
| Effective Pixels | 1.3 Mega Pixels |
| Built-in Lens | 2.8-12mm Mega Pixel Lens |
| Signal System | PAL/NTSC |
| Horizontal Resolution | PAL:1280X720P 25F/S NTSC:1280X720P 30F/S |
| Sync. System | Internal Sync. |
| Sensor Area | 4.8mmx3.6mm |
| Video Output | 75Ω BNC |
| S/N Ratio | More than 50dB (AGC OFF) |
| White Balance | Auto Tracking White Balance |
| Shutter Speed | 1/25~50,000 Sec. |
| Illumination for Infrared Switching | 3 Lux |
| Infrared Wavelength | 850nm |
| Minimum Illumination | 0 Lux (Infrared Lamps Turn on) |
| IR Leds | 35 pcs |
| IR Radiation Distance | 30m |
| Working Temperature | -50°F~-122°F (-10°C~-50°C) |
| Storage Temperature | -68°F~-140°F (-20°C~-60°C) |
| Power Requirement | DC12V, Max Power Comsumption Less Than 5W (When the infrared lamps turn on) |
