| Camera | |
| Image Sensor | 1/3"Sensor |
| Signal System | NTSC / PAL(Euro Version) |
| Effective Pixels | 1280(H)×720(V) |
| Min. Illumination | 0.01 Lux @ (AGC ON),0 Lux with IR |
| Shutter Speed | NTSC: 1/30 ~ 1/50,000 PAL: 1/25 ~ 1/50,000 |
|
Lens
|
2.8mm |
| Day & Night | ICR |
| Synchronization | Internal synchronization |
| Video Frame Rate | NTSC:720p@30fps/PAL:720p@25fps |
| HD Video Output | 1 Analog HD output |
| S/N Ratio | More than 52dB |
| General | |
| Working Temperature /Humidity |
-40°F - 140°F (-40 °C - 60 °C) |
| Humidity 90% or less (non-condensing) | |
| Power Supply | 12V DC |
| Power Consumption | Max.3.5W |
| Weather Proof Ratings | IP66 |
| IR Range | 65ft(20m) |
| Dimension | 3.5" × 2.3" (89.6 ×59.1 mm) |
| Weight | 0.9lb(400g) |
