FEATURES

	High-Res 620 TV Line The camera is powered by NEXT chipset that is embodied the top grade of the world at 620 TVL resolution be own image signal technology which is to change the frequency of luminance signal adaptively by a monitoring sector.
	2D DNR (2D DIGITAL NOISE REDUCTION) Improved S/N ratio 50dB and more sharp and noiseless low light image quality provided by built-in noise reduction (2DDNR: 2D Digital Noise Reduction) function.
	OSD CAMERA SETUP It has have a small program built-in to the camera to help users to setup the camera function without difficulties. No more reading a manual and tipping dip-switches to configure the camera.

Resolution	620 TV Line
Sensor	1/3 inch Sony Super HAD II CCD
Total Pixels	811(H) x 508(V) 410K pixels (NTSC)
Effective Pixels	768(H) x 494(V) 380K pixels (NTSC)
Scanning System	2:1 Interface
S/N (Y signal)	More than 50 dB (AGC Off)
Frequency	Horizontal : 15.734KHz / Vertical : 59.94Hz (NTSC)
Video Output	CVBS : 1.0 Vp-p Comp. 75Ω
Minimum Illumination	0.1 Lux at F1.2 (Color) / 0.01 Lux (B/W)
White Balance	ATW1 / ATW2 / AWC->SET / Manual Adjustable
Electronic shutter speed	Auto (1/60sec ~ 1/100,000sec) (NTSC)
O.S.D	Built-in
Blacklight Compensation (BLC)	OFF / BLC / HLC Selectable
Auto Gain Control (AGC)	Low / Middle / High / Off Selectable
2DDNR (2D Digital Noise Reduction)	On / Off
Day & Night	Auto / Color / BW / EXT
Privacy	OFF / ON (8 Zone)
Motion Detection	OFF / ON (Motion size : 28 × 15.4 AREA)
Image Conversion	ON / OFF
Sharpness	Adjustable
Operating Temp. / Humidity	-10°C ~ 50°C / 30%~80% RH
Storage Temp. / Humidity	-20°C ~ 60°C / 20%~90% RH
Power Source	DC 12V / AC 24V : DUAL POWER
